MVI69-GSC ♦ CompactLogix or MicroLogix Platform
Generic ASCII Serial Communication Module
Printing a Configuration File
1
Select the module icon, and then click the right mouse button to open a shortcut
menu.
2
On the shortcut menu, choose V
Configuration window.
3
In the View Configuration window, open the F
action opens the Print dialog box.
4
In the Print dialog box, choose the printer to use from the drop-down list, select
printing options, and then click OK.
ProSoft Technology, Inc.
C
. This action opens the View
IEW
ONFIGURATION
menu, and choose P
ILE
Contents
User Manual
. This
RINT
Page 36 of 83
