Package Contents - ProSoft Technology MVI56-PNPM User Manual

MVI56-PNPM ♦ ControlLogix Platform
Phantom Network Protocol Master Communication Module
100 Mbytes of free hard disk space (or more based on application
requirements)
256-color VGA graphics adapter, 800 x 600 minimum resolution (True Color
1024 × 768 recommended)
CD-ROM drive
HyperTerminal or other terminal emulator program.
Note: You can install the module in a local or remote rack. For remote rack installation,
the module requires EtherNet/IP or ControlNet communication with the processor.
1.2

Package Contents

The following components are included with your MVI56-PNPM module, and are
all required for installation and configuration.
Important: Before beginning the installation, please verify that all of the following
items are present.
Qty. Part Name
MVI56-
1
PNPM
Module
1 Cable
3 Cable
2 Adapter
1 ProSoft
Solutions
CD
If any of these components are missing, please contact ProSoft Technology
Support for replacement parts.
Page 10 of 91
Part Number Part Description
Phantom Network Protocol Master Communication
MVI56-PNPM
Module
RS232 Null For RS232 Connection to the CFG Port
Modem
Cable #14, RJ45 to For DB9 Connection to Module's Port
DB9 Male Adapter
1454-9F Two Adapters, DB9 Female to Screw Terminal.
For RS422 or RS485 Connections to Port 1 and 2
of the Module
Contains sample programs, utilities and
documentation for the MVI56-PNPM module.
Start Here
ProSoft Technology, Inc.
January 2, 2008
