MVI69-GSC ♦ CompactLogix or MicroLogix Platform
Generic ASCII Serial Communication Module
Object in GSCInStat
Port[1].TxState
Port[1].TxCharCnt
Port[1].TxMsgCnt
Port[1].ErrorWord
ProSoft Technology, Inc.
Block Description
Offset
33 Port 2 transmit state:
0 = Waiting for Data to Send
1 = RTS On
2 = RTS Timeout
3 = Sending data
4 = Waiting for RTS Off
5 = RTS turned off
30 = Intercharacter Delay
31 = Intercharacter Delay
32 = Intercharacter Delay
100 = Message Delay before Transmit
101 = Message Delay before Transmit
34 Port 2 transmit character count
35 Port 2 transmit block count
36 Port 2 error word
