Connector monitoring
Line-side connector monitoring can be deactivated.
Response when connector removed
You use this device parameter to determine how the motor starter is to respond when the
connector is removed:
● Group fault
● Group fault only after ON command
● Group warning
Settings
Connector monitoring
Response when connector
removed
Messages and actions
Connector monitoring deactivated
Connector disconnected on line side
3.7.5.1

Motor connector

The "connector monitoring" function is only valid for the infeed connector.
A connector monitoring function for the motor connector can be logically combined with the
thermistor cable and/or thermistor evaluation function.
If a motor is operated without a thermistor, you can activate thermistor monitoring
(thermoclick) and use it to monitor the connector by means of a wire jumper on the motor
terminal board or in the motor connector.
Note
In this case, the "temperature sensor overload" message must be interpreted as a removed
motor connector.
M200D AS-Interface Standard
Manual, 08/2014, A5E02548958A/RS-AA/004
Device parameter
Deactivated
Group fault
Message
Default setting
Deactivated
•
Line side
•
Group fault
•
Group fault only after ON command
•
Group warning
•
No monitoring on plugged-in connector
Dependent on parameterization
Functions
3.7 System monitoring
Setting range
Action
63
