31
Note: Pager IDs are used in the alarm provisioning screen to designate the primary and secondary
person/device being paged when an alarm condition occurs or clears.
2. Under the Type column select Numeric from the drop-down menu, see Figure 2.16.
3. Enter the phone number of the numeric pager under the Phone/Domain heading, followed by 7
commas (e.g. 555-1212,,,,,,,). Placing a comma after the phone number initiates a two second
pause (per comma). This allows enough time for the pager to answer before the NetGuardian sends
the alarm information.
The Baud/Wfmt and IPA fields are not used from numeric pager types.
2.6.4

Text Paging Setup

Text pages can receive information including the point addresses of alarms, the alarm description, time
of the alarm, and state (alarm or clear). The text pages may be viewed using a terminal such as
HyperTerminal.
Use the following steps to configure the text paging settings:
1. From the Edit menu > Notification screen, select an ID number to use, refer to Figure 2.16.
Note: Pager IDs are used in the alarm provisioning screen to designate the primary and secondary
person/device being paged when an alarm condition occurs or clears.
2. Under the Type column select Text from the drop-down menu, see Figure 2.16.
3. Enter the phone number of the text paging device under the Phone/Domain heading.
4. Set the pager data rate (i.e. 300, 1200, 2400 or 9600). The default baud is 1,200.
5. Select a pager word format (e.g Data bits: 7 or 8, Parity: none (N), even (E) or odd (O), and Stop
Bits: 1). The default setting is 7, Even,1.
To set up text paging from T/Mon see the T/Mon user manual.
2.6.5

Email Notification Setup

The email pager provides alarm notification via email, with a description similar to that of the alpha-
numeric pager.
Use the following steps to configure the email notification settings:
1. From the Edit menu > Notification screen, select an ID number to use, see to Figure 2.16.
Note: Pager IDs are used in the alarm provisioning screen to designate the primary and secondary
person/device being paged when an alarm condition occurs or clears.
2. Under the Type column, select Email from the drop-down menu, see Figure 2.16.
Fig. 2.18. Email notification from the NetGuardian
