NetGuardian Test Fixture
USER MANUAL
Visit our website at www.dpstelecom.com for the latest PDF manual and FAQs.
D-UM-TSTBX

Advertisement

loading
Need help?

Need help?

Do you have a question about the NetGuardian 832A G2 and is the answer not in the manual?

Questions and answers

Summary of Contents for DPS Telecom NetGuardian 832A G2

  • Page 1 “Yo u r Part n ers i n Net w o rk Al arm Man ag emen t ” NetGuardian Test Fixture USER MANUAL Visit our website at www.dpstelecom.com for the latest PDF manual and FAQs. D-UM-TSTBX...
  • Page 2 Notice The material in this manual is for information purposes and is subject to change without notice. DPS Telecom shall not be liable for errors contained herein or consequential damages in connection with the furnishing, performance, or use of this...
  • Page 3: Table Of Contents

    Contents Visit our w ebsite at w w w .dpstelecom .com for the latest PDF m anual and FAQs Introduction ....................1 Shipping List ....................2 Power and Data Connections ....................3 Simulating Discrete Alarms ....................5 Simulating Analog Alarms ....................6 Reading NetGuardian Relay Output ....................7 Technical Support ....................8...
  • Page 4: Introduction

    This User Manual contains all the information you need to successfully connect and operate the Test Fixture. However, if you run into a problem or require additional help, DPS Telecom's courteous Technical Support staff is ready to provide the assistance you need. Call 1-800-622-3314 or email support@dpstele.com.
  • Page 5: Shipping List

    While unpacking the Test Fixture, please make sure that all of the following items are included. If some parts are missing, or if you ever need to order new parts, please refer to the part numbers in parentheses and call DPS Telecom Customer Service at 1-800-622-3314.
  • Page 6: Power And Data Connections

    Power and Data Connections Pow er Input Pow er Output Fig. 2. Power input and output The Test Fixture has two power connections. If one is looking at the control panel of the Test Fixture, the left-hand power connection, nearest to the Analogs 7–8 connector, is a power input providing power to the Test Fixture; the right-hand power connection is a power output providing power to the NetGuardian unit connected to the Test Fixture.
  • Page 7 Note: Push all power plugs firmly into their sockets. Note that the connections are keyed and the plug must be properly aligned within the socket. 4. Using the provided analog signal cable (if your unit has analog inputs), connect the Test Fixture connector marked "Analogs 7–8"...
  • Page 8: Simulating Discrete Alarms

    Simulating Discrete Alarms Fig. 4. Alarm input switches The toggle switches on the control panel of the Test Fixture simulate discrete alarm inputs. The number of toggle switches will depend on the Test Fixture purchased. The toggle switches are OFF when in the DOWN position, and ON when in the UP position. To simulate a discrete alarm, move a toggle switch to the on position.
  • Page 9: Simulating Analog Alarms

    Simulating Analog Alarms Fig. 5. Analog input controls The eight dials on the control panel of the Test Fixture simulate analog inputs. When turned fully CLOCKWISE, the analog switch outputs 0 volts; when turned fully COUNTERCLOCKWISE, the analog switch will output a voltage that the NetGuardian will detect as approximatley -44 volts. To simulate an analog alarm, turn a dial counterclockwise.
  • Page 10: Reading Netguardian Relay Output

    Reading NetGuardian Relay Output Fig. 7. Fuse alarm and control relay indicators The nine LEDs on the control panel of the Test Fixture indicate fuse alarm and control relay outputs from the NetGuardian. The LED labeled "FA" indicates the fuse alarm, and will light red if the NetGuardian's fuse fails. The LEDs labeled 1–8 indicate control relay outputs.
  • Page 11: Technical Support
