99
Sends Unsolicited Responses
x Never
o Only certain objects
o Sometimes (attach explanation)
o ENABLE/DISABLE UNSOLICITED
Function
codes supported
Default Counter Object/Variation:
x No Counters Reported
o Default Object
DNP V3.0
DEVICE PROFILE DOCUMENT
(Also see the DNP 3.0 Implementation Table in Section 4.6.2)
Sends Multi-Fragment Responses:
No
Yes
Sequential File Transfer Support: No
Append File Mode: No
Custom Status Code Strings: No
Permissions Field: No
File Events Assigned to Class: No
File Events Send Immediately: No
Multiple Blocks in a Fragment: No
Max Number of Files Open: 0
DNP V3.0 Implementation Table
The following table identifies which object variations, function codes, and qualifiers the NetGuardian
832A/864A G5 DNP3 supports in both request messages and in response messages. For static (non-
change-event) objects, request send with qualifiers 00, 01, 06, 07, or 08 will be responded with qualifiers
00 or 01.
OBJECT
Objec
Variatio
t
n Description
Numb
Number
er
Sends Static Data in Unsolicited
Responses:
x Never
o When Device Restarts
o When Status Flags Change
Counters Roll Over at:
x No Counters Reported
o Configurable (attach explanation)
o 16 Bits
o 32 Bits
o Other Value: ____
o Point-by-point list attached
REQUEST
(Library will parse)
Function Qualifiers
Codes (dec) Codes (hex)
RESPONSE
(Library will respond with)
Function
Qualifiers
Codes
Codes (hex)
(dec)
