DPS Telecom NetGuardian 832A G5 User Manual page 20

15
v3 Engine ID
Get
Set
Trap / v3
Context Name
ID
Username
Access Mode
Auth Pass
Priv Pass
IPA
Port
Format
Retry
Seconds
Specifies the v3 Engine ID for your NetGuardian device. DPS recommends
using the default ID for the unit, which is automatically generated by the
unit.The default ID is generated according to RFC3411 and is based on the
unit's unique MAC address and DPS Telecom's SNMP enterprise number.
Note: To have the unit generate a unique Engine ID, clear the v3 Engine ID
field and press the Submit key.
SNMP Communities
Community name for SNMP requests.
Community name for SNMP SET requests.
Community name for SNMP TRAP requests. In SNMP v3, defines the context
name field of a v3-Trap.
Note: Make sure that your community strings match those used by the SNMP
manager. In v1 and v2c, community strings are security passwords; if the
strings do not match, the SNMP manager will not accept Traps from the
NetGuardian G5. Community strings are case sensitive.
The user number designated for a v3-user. The NetGuardian G5 supports up to
four
v3-User profiles.
The name of the user for which an SNMPv3 management operation is
performed.
This identifies the security modes available when SNMPv3 is utilitized. The
modes are as follows:
· No-Auth, No-Priv- This access mode does not require authentication and
does not require encryption. This mode is the least secure and is comparable
to v1 and v2c.
· Auth-MD5,No-Priv- Provides authentication based on the MD5 algorithm
and does not require encryption.
· Auth-SHA,No-Priv- Provides authentication based on the SHA algorithm and
does not require encryption.
· Priv Auth-MD5- Provides authentication based on the MD5 algorithm and
provides DES 56-bit encryption based on the CBC-DES standard.
· Priv Auth-SHA- Provides authentication based on the SHA algorithm and
provides DES 56-bit encryption based on the CBC-DES standard.
This field contains the password used with either MD5 or SHA authentication
algorithms.
This field contains the password used with privatization encryption.
Global Trap Managers
Defines the SNMP trap manager's IP address. Set to 255.255.255.255 if not
using.
The SNMP port is the UDP port set by the SNMP manager to receive traps,
usually set to 162.
Select between v1-Trap, v2c-Trap, v2c-Inform, or v3-Trap.
Number of times the NetGuardian G5 will resend SNMP v2c-Informs
Time interval in seconds between attempts to resend SNMP v2c-Informs.
v3-Users
