Ventilation

4.9
Ventilation
Ensuring Ventilation
Do not cover or block ventilation openings. Otherwise the system could overheat and be seriously
damaged.
Buzz On-Wall Ventilation Openings
Ventilation openings are located on the top, bottom and sides of the system as marked below.
NOTE: If the computer is wall mounted the "wave" cover must always be mounted.
Ventilation Openings on Additional Touch Display On-Wall
Ventilation openings are located on the bottom and sides of the system as marked below.
NOTE: The airflow marked above is inside the wall.
52
Figure 27
Figure 28
Site Planning Manual Rev. 1.1 Buzz Ver. 2.0
