For the fitter
2.6

Maintenance

The outside of the storage heater does not require any special maintenance. To clean, wipe using a
soft cloth or damp sponge only. Do not use any abrasive agents or aggressive detergents.
Caution! Always fully disconnect the appliance from the power supply before carrying out any
!
maintenance work.
To ensure a long service life, it is recommended to have a specialist technician inspect the
anti-corrosion anode (magnesium anode) in the appliance once per year. This check may need to be
carried out more frequently in areas with particularly aggressive water – ask the fitter or your local
water supply company for information.
The appliance is protected against overheating by a safety temperature limiter which interrupts
all phases. If the safety temperature limiter has been triggered, an authorised specialist technician
is required to carry out the repair work. The high limit safety cut-out can be reset by pressing the
pushbutton (marked Safety) on the controller below the control panel cover.
2.7

Technical specifications

Type
Rated voltage
Power consumption
Nominal capacity
Power consumption
in stand-by mode
Drawable quantity
of mixed water
(1)
at 40 °C
Weight (empty)
Weight (wet)
Dimensions
A
B
C
D
E
H
I
K
M
X
Permissible opera-
ting pressure
Degree of protec-
tion
Mark of conformity
(1)
Cold water inlet 15 °C and cylinder temperature 65 °C
10
EWH Basis
EWH Basis
30 / 30 N
50 / 50 N
W
W
2000
2000
Litres
30
50
kWh/
0.73
0.93
d
Litres
56,2
101,5
kg
16
21
kg
46
71
mm
100
100
mm
296
296
mm
47
47
mm
390
390
mm
530
591
mm
585
840
mm
102
296
mm
386
386
mm
78
78
mm
G 1/2"
G 1/2"
MPa
EWH Basis
EWH Basis
EWH Basis
80 / 80 N
100 / 100 N
120 / 120 N
1/N/PE ~ 230V
2000
2000
80
100
1.16
1.48
144,3
186
26
30
106
130
100
100
274
274
28
28
470
470
583
735
810
962
255
255
485
485
75
75
G 3/4"
G 3/4"
0,6
Protection against water jets (IP 25)
See rating plate
EWH Basis
EWH Basis
150 / 150 N
200 / 200 N
2000
2000
120
150
1.71
2.01
227,9
291
34
41
154
191
100
100
274
274
28
28
470
470
889
1125
1116
1352
255
255
485
485
75
75
G 3/4"
G 3/4"
G 3/4"
2200
200
2.90
385,3
50
250
100
274
28
470
1425
1652
255
485
75
