  • Page 1 DDLE Basis 11 DDLE Basis 13 DDLE Basis 18 DDLE Basis 18/21/24 DDLE Basis 27 Elektronisch gesteuerter Durchlauferhitzer Bedienungs- und Installationsanleitung ......2 Electronically controlled instantaneous water heater Operating and installation instructions ......18 Elektronicznie sterowany przepływowy ogrzewacz wody Instrukcja obsługi i instalacji ..........34...
  • Page 4 LR 1-A 18 Nm ADEo 70 WD...
  • Page 5: Equipment Description

    For users and contractors Thank you for purchasing this instantaneous water heater from AEG Haustechnik. You have chosen a high-grade device made in Germany. Even during the development and manufacture, AEG Haustechnik recognises the high value of manufacturing processes that are environmentally responsible and treat resources with care. Thanks to many product innovations, devices made by AEG Haustechnik are amongst the most energy-efficient in their class.
  • Page 6: Dhw Output

    For users and contractors DHW output Subject to season, the following maximum mixed water or draw-off capacities result for different cold water temperatures (see Table 1): ϑ Cold water inlet temperature ϑ Mixed water temperature ϑ Outlet temperature. Shower, washing hands, filling a bath, etc. Kitchen sink and when using thermostatic valves.
  • Page 7: Installation Instructions

    For contractors Installation instructions Only trained and authorised experts must install the device and make the electrical connection under full observance of these installation instructions. Equipment layout 1 Temperature selector 17 Flow sensor 2 Equipment cap 18 Temperature selector plug “set T” 3 Base, back panel 19 Type plate 4 DHW compression fitting...
  • Page 8 For contractors 19). the risk of frost, as water residues remain inside the device. Water installation: Steel, copper or plastic pipework. Copper or plastic pipework*. * The instantaneous water heater can reach operating temperatures up to 60°C. In case of faults, loads up to 95 °C / 1.2 MPa can occur temporarily in the installation.
  • Page 9: Standard Installation

    For contractors Standard installation for contractors Power: Unfinished walls - top; Water: Unfinished walls General installation information At the factory, the device is prepared for a power connection from the top from an installation below the plaster (see Fig. Important information regarding the DDLE Basis 18/21/24 with connected load changeover In its delivered condition the device is set to 21 kW.
  • Page 10: Power Supply

    For contractors Never replace the pressure limiter when using a thermostatic valve. Never use the shut-off valve in the cold water supply (23) to reduce the fl ow rate. Power supply 1 heating system 2 High limit safety cut-out 3 Safety pressure limiter Important information: The protection level IP 25 (hoseproof) is only assured if the cable grommet is fi...
  • Page 11: Alternative Installation Methods

    For contractors Alternative installation methods for contractors Power supply: unfinished walls - below, maximum demand relay; undersink installation, water connections - top; water: finished walls Power supply – unfinished walls - below a Push the cable grommet (4) over the power cable. b Break out the cable grommet knock-out in the back panel.
  • Page 12: Specification

    For contractors Specification and application areas for contractors Specification (The details on the type plate apply) Type DDLE Basis 11 DDLE Basis 13 DDLE Basis 18 DDLE Basis 18/21/24 DDLE Basis 27 with selectable output Part number Rated output Rated current A 16 19.5...
  • Page 13: Troubleshooting

    For users and contractors Troubleshooting by the user Fault Cause Remedy The heating system inside the No voltage. User / Contractor: instantaneous water heater will not Check the fuses in your fuse board. start in spite of the tap being fully open. The start-up volume required to start the User / Contractor: heater has not been reached.
  • Page 14: Special Accessories

    For contractors No hot water; throughput High limit safety cut-out triggered or Check high limit safety cut-out and activate, if required ( A 15). > 3 l/min cable break Traffic light display: Test the heating system resistor ( A 16) Heating system faulty constant yellow indication and replace, if required.
  • Page 15 Customer service and warranty Guarantee For guarantees please refer to the respective terms and conditions of supply for your country. The installation, electrical connection and first operation of this appliance should be carried out by a qualified installer. The company does not accept liability for failure of any goods supplied which have not been installed and operated inaccordance with the manufacturer‘s instructions.
  • Page 16: Environment And Recycling

    Environment and recycling 10. Environment and recycling Recycling of obselete appliances Appliances with this label must not be disposed off with the general waste. They must be collected separately and disposed off according to local regulations.
  • Page 17 07 11 / 9 88 67 - 11 0 73 - 6 23 11 41 07 11 / 9 88 67 - 77 Polska AEG Oddzial Stiebel Eltron Polska Sp. z.o.o. Ul. Instalatorów 9 02-237 Warszawa Tel. 0 22 - 8 46 48 20...
