Autorequest (CHNL_CFG[2:0] = 010)
In autorequest mode, it is only necessary for the controller to receive a single request to enable it to complete the entire DMA cycle. This
allows a large data transfer to occur without significantly increasing the latency for servicing higher priority requests or requiring multiple
requests from the processor or peripheral. This mode is useful for a memory-to-memory copy application.
Autorequest is not suitable for peripheral use, except for the ADC sequencer mode where a number of peripheral operations must be
completed.
In this mode, the controller can be configured to use either the primary or alternate data structure. After the channel is enabled, when the
controller receives a request, it performs the following operations:
1. The controller performs min(2
register and N is the number of transfers. If the number of transfers remaining is zero, the flow continues at Step 3.
2. A request for the channel is automatically generated. The controller arbitrates. If the channel has the highest priority, the DMA cycle
continues at Step 1.
3. At the end of the transfer, the controller generates an interrupt for the corresponding DMA channel.
Ping-Pong (CHNL_CFG[2:0] = 011)
In ping-pong mode, the controller performs a DMA cycle using one of the data structures and then performs a DMA cycle using the
other data structure. The controller continues to switch from primary to alternate to primary until it reads a data structure that is invalid,
or until the host processor disables the channel.
This mode is useful for transferring data from peripheral to memory using different buffers in the memory. In a typical application, the host
must configure both primary and alternate data structures before starting the transfer. As the transfer progresses, the host can subsequently
configure primary or alternate control data structures in the interrupt service routine when the corresponding transfer ends.
The DMA controller interrupts the processor after the completion of transfers associated with each control data structure. The individual
transfers using either the primary or alternate control data structure work exactly the same as a basic DMA transfer.
Memory Scatter-Gather (CHNL_CFG[2:0] = 100 or 101)
In memory scatter-gather mode, the controller must be configured to use both the primary and alternate data structures. The controller
uses the primary data structure to program the control configuration for alternate data structure. The alternate data structure is used for
actual data transfers, which are similar to an autorequest DMA transfer. The controller arbitrates after every primary transfer. The controller only
requires one request to complete the entire transfer. This mode is used when performing multiple memory-to-memory copy tasks. The
processor can configure all of the tasks simultaneously and does not need to intervene in between each task. The controller generates the
corresponding DMA channel interrupt in the NVIC when the entire scatter-gather transaction completes using a basic cycle.
In this mode, the controller receives an initial request and then performs four DMA transfers using the primary data structure to program
the control structure of the alternate data structure. After this transfer completes, the controller starts a DMA cycle using the alternate
data structure. After the cycle completes, the controller performs another four DMA transfers using the primary data structure. The
controller continues to switch from primary to alternate to primary until the processor configures the alternate data structure for a basic
cycle or until the DMA reads an invalid data structure.
Table 84 lists the fields of the CHNL_CFG memory location for the primary data structure, which must be programmed with constant
values for memory scatter-gather mode.
Table 84. CHNL_CFG for Primary Data Structure in Memory Scatter-Gather Mode, CHNL_CFG[2:0] = 100
Bits Name
[31:30] DST_INC
[29:28] DST_SIZE
[27:26] SRC_INC
[25:24] SRC_SIZE
[23:18] Reserved
[17:14] R_POWER
[13: 4] N_MINUS_1
3 Reserved
[2:0] CYCLE_CTRL
R_POWER , N) transfers for the channel, where R_POWER is Bits[17:14] of the control data configuration
Description
10: configures the controller to use word increments for the address.
10: configures the controller to use word transfers.
10: configures the controller to use word increments for the address.
10: configures the controller to use word transfers.
Undefined. Write as 0.
0010: indicates that the DMA controller is to perform four transfers.
Configures the controller to perform N DMA transfers, where N is a multiple of 4.
Undefined. Write as 0.
100: configures the controller to perform a memory scatter-gather DMA cycle.
