UG-549

REGISTER SUMMARY: GENERAL-PURPOSE TIMER 0

Table 226. Timer 0 Register Summary
Address
Name
0x40000000
T0LD
0x40000004
T0VAL
0x40000008
T0CON
0x4000000C
T0CLRI
0x40000010
T0CAP
0x4000001C
T0STA

REGISTER DETAILS: GENERAL-PURPOSE TIMER 0

16-Bit Load Value Register
Address: 0x40000000, Reset: 0x0000, Name: T0LD
Table 227. Bit Descriptions for T0LD
Bits
Bit Name
[15:0]
LOAD
16-Bit Timer Value Register
Address: 0x40000004, Reset: 0x0000, Name: T0VAL
Table 228. Bit Descriptions for T0VAL
Bits
Bit Name
[15:0]
VAL
Control Register
Address: 0x40000008, Reset: 0x000A, Name: T0CON
Table 229. Bit Descriptions for T0CON
Bits
Bit Name
[15:13]
RESERVED
12
EVENTEN
[11:8]
EVENT
7
RLD
[6:5]
CLK
Description
16-bit load value register
16-bit timer value register
Control register
Clear interrupt register
Capture register
Status register
Description
Load value. The up/down counter is periodically loaded with this value if
periodic mode is selected (T0CON[3] = 1). LOAD writes during up/down
counter timeout events are delayed until the event has passed.
Description
Current count. Reflects the current up/down counter value. Value delayed
two PCLK cycles due to clock synchronizers.
Description
Reserved.
Event select. This bit enables and disables the capture of events. Used in
conjunction with the EVENT select range: when a selected event occurs,
the current value of the up/down counter is captured in T0CAP.
0: events are not captured.
1: events are captured.
Event select range. Timer event select range (0 to 15).
Reload control. RLD is only used for periodic mode; this bit allows the user
to select whether the up/down is reset only on a timeout event or also
when T0CLRI[0] is set.
1: up/down counter is reset when T0CLRI[0] is set.
0: up/down counter is only reset on a timeout event.
Clock select. These bits select a timer clock from the four available clock
sources.
00: PCLK.
01: HCLK.
10: LFOSC (32 kHz oscillator).
11: HFXTAL, if CLKCON0[11] = 1.
11: HFOSC, if CLKCON0[11] = 0.
Rev. C | Page 160 of 192
ADuCM310 Hardware Reference Manual
Reset
Access
0x0000
RW
0x0000
R
0x000A
RW
0x0000
W
0x0000
R
0x0000
R
Reset
Access
0x0
RW
Reset
Access
0x0
R
Reset
Access
0x0
R
0x0
RW
0x0
RW
0x0
RW
0x0
RW
