Analog Devices ADuCM310 Hardware Reference Manual page 162

UG-549
Status Register
Address: 0x4000001C, Reset: 0x0000, Name: T0STA
Table 232. Bit Descriptions for T0STA
Bits Bit Name
[15:8] RESERVED
7 PDOK
6 BUSY
[5:2] RESERVED
1 CAP
0 TMOUT
Description
Reserved.
T0CLRI synchronization. This bit is set automatically when the user sets
T0CLRI[0] = 1. It is cleared automatically when the clear interrupt request
crosses clock domains and takes effect in the timer clock domain.
0: CLR. The interrupt is cleared in the timer clock domain.
1: SET. T0CLRI[0] is being updated in the timer clock domain.
Timer busy. This bit informs the user that a write to T0CON is still crossing
into the timer clock domain. Check this bit after writing T0CON, and suppress
further writes until this bit is cleared.
0: CLR. Timer ready to receive commands to T0CON.
1: SET. Timer not ready to receive commands to T0CON.
Reserved.
Capture event pending.
0: CLR. No capture event is pending.
1: SET. A capture event is pending.
Timeout event occurred. This bit is set automatically when the value of the
counter reaches zero while counting down or reaches full scale when counting
up. This bit is cleared when T0CLRI[0] is set by the user.
0: CLR. No timeout event has occurred.
1: SET. A timeout event has occurred.
Rev. C | Page 162 of 192
ADuCM310 Hardware Reference Manual
Reset Access
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
