UG-549

REGISTER SUMMARY: GENERAL-PURPOSE TIMER 2

Table 240. Timer 2 Register Summary
Address
0x40000800
0x40000804
0x40000808
0x4000080C
0x40000810
0x4000081C

REGISTER DETAILS: GENERAL-PURPOSE TIMER 2

16-Bit Load Value Register
Address: 0x40000800, Reset: 0x0000, Name: T2LD
Table 241. Bit Descriptions for T2LD
Bits Bit Name
[15:0] LOAD
16-Bit Timer Value Register
Address: 0x40000804, Reset: 0x0000, Name: T2VAL
Table 242. Bit Descriptions for T2VAL
Bits Bit Name
[15:0] VAL
Control Register
Address: 0x40000808, Reset: 0x000A, Name: T2CON
Table 243. Bit Descriptions for T2CON
Bits Bit Name
[15:13] RESERVED
12 EVENTEN
[11:8] EVENT
7 RLD
[6:5] CLK
Name Description
T2LD 16-bit load value register
T2VAL 16-bit timer value register
T2CON Control register
T2CLRI Clear interrupt register
T2CAP Capture register
T2STA Status register
Description
Load value. The up/down counter is periodically loaded with this value if
periodic mode is selected (T2CON[3] = 1). LOAD writes during up/down
counter timeout events are delayed until the event has passed.
Description
Current count. Reflects the current up/down counter value. Value delayed
two PCLK cycles due to clock synchronizers.
Description
Reserved.
Event select. This bit enables and disables the capture of events. Used in
conjunction with the EVENT select range: when a selected event occurs
the current value of the up/down counter is captured in T2CAP.
0: events are not captured.
1: events are captured.
Event select range. Timer event select range (0 to 15).
Reload control. RLD is only used for periodic mode; this bit allows the user
to select whether the up/down counter is reset only on a timeout event or
also when T2CLRI[0] is set.
1: up/down counter is reset when T2CLRI[0] is set.
0: up/down counter is only reset on a timeout event.
Clock select. These bits select a timer clock from the four available clock
sources.
00: PCLK.
01: HCLK.
10: LFOSC, 32 kHz oscillator.
11: HFXTAL, if CLKCON0[11] = 1.
11: HFOSC, if CLKCON0[11] = 0.
ADuCM310 Hardware Reference Manual
Rev. C | Page 166 of 192
Reset RW
0x0000 RW
0x0000 R
0x000A RW
0x0000 W
0x0000 R
0x0000 R
Reset Access
0x0 RW
Reset Access
0x0 R
Reset Access
0x0 R
0x0 RW
0x0 RW
0x0 RW
0x0 RW
