TANDBERG Codec C Series Api Manual page 73

TANDBERG Codec C60 and Codec C40
Contents Contents Introduction Introduction
The Phonebook commands,
cont...
xCommand Phonebook Folder Delete
Delete an existing folder from the local phonebook.
FolderId: A unique identifier for the folder, which was created when the xCommand Phonebook Folder
Add command was issued.
Parameters:
FolderId(r): <S: 0, 255>
Example:
xCommand Phonebook Folder Delete FolderId:localGroupId-3
OK
*r PhonebookFolderDeleteResult (status=OK):
** end
D14642.02—MAY 2010
About the API About the API xConfiguration xConfiguration
xCommand
xCommand xCommand xStatus xStatus
The Phonebook commands,
cont...
xCommand Phonebook Contact Add
Add new contact to the local phonebook. Stored internally in the system. Returns the ContactId (Name:
localContactId-1), which is a unique Id of the contact.
Name: The name of the contact.
FolderId: A unique identifier for the folder, which was created when the xCommand Phonebook Folder
Add command was issued.
ImageURL: The URL to an image.
Title: The title of the contact.
Number: The phone number or address of the contact.
Protocol: Select H323 or SIP protocol.
CallRate: Set a call rate.
Device: Set which type of device to call to.
Parameters:
Name(r): <S: 0, 255>
FolderId: <S: 0, 255>
ImageURL: <S: 0, 255>
Title: <S: 0, 255>
Number: <S: 0, 255>
Protocol: <H323/SIP>
CallRate: <0..65534>
Device: <Mobile/Other/Telephone/Video>
Example:
xCommand Phonebook Contact Add Name:"John Doe" Number:12345
OK
*r PhonebookContactAddResult (status=OK):
Name: localContactId-1
** end
73
