The Video Output status,
cont...
xStatus Video Output Legacy [3] Resolution RefreshRate
Shows the resolution refresh rate (Hz) for the video output Legacy (Composite).
Value space of the result returned:
<1..300>
Example:
xStatus Video Output Legacy 3 Resolution RefreshRate
*s Video Output Legacy 3 Resolution RefreshRate: 60
** end
D14642.02—MAY 2010
About the API About the API xConfiguration xConfiguration
xStatus
xCommand xCommand xStatus xStatus
The Video Layout status
xStatus Video Layout
Shows the top level overview of the video status.
Example:
xStatus Video Layout
*s Video Layout Site 1 Output 1 FamilyName: "speaker"
*s Video Layout Site 1 Output 1 FullFamilyName: "speaker-sv-on"
*s Video Layout Site 1 Output 1 FamilyNumber: 1027
*s Video Layout Site 1 Output 1 GraphicName: "1top-1small"
*s Video Layout Site 1 Output 1 GraphicNumber: 1017
*s Video Layout Site 1 Output 1 Descriptor: 4
*s Video Layout Site 1 Output 1 DescriptorOutput: 1
*s Video Layout Site 1 Output 1 Frame 1 PositionX: 1333
*s Video Layout Site 1 Output 1 Frame 1 PositionY: 59
*s Video Layout Site 1 Output 1 Frame 1 Width: 7334
*s Video Layout Site 1 Output 1 Frame 1 Height: 7334
*s Video Layout Site 1 Output 1 Frame 1 Layer: 1
*s Video Layout Site 1 Output 1 Frame 1 VideoSourceType: "site"
*s Video Layout Site 1 Output 1 Frame 1 VideoSourceId: 27
*s Video Layout Site 1 Output 1 Frame 1 InputNumber: 1
*s Video Layout Site 1 Output 1 Frame 1 Filename: ""
-
- continues with the video layout status for the Sites [1..n], Outputs [1..3]
and Frames [1..6].
** end
xStatus Video Layout Site [1..n] Output [1..3] FamilyName
Shows the name of the video layout family.
Value space of the result returned:
<S: 0, 100>
Example:
xStatus Video Layout Site 1 Output 1 FamilyName
*s Video Layout Site 1 Output 1 FamilyName: "full"
** end
