The SerialPort settings
xConfiguration SerialPort BaudRate
Specify the baud rate (data transmission rate, bits per second) for the COM 1 port on the codec. The
default value is 38400.
Connection parameters for the COM port: Data bits: 8 Parity: None Stop bits: 1 Flow control: None.
Value space: <9600/19200/38400/57600/115200>
Range: Select a baud rate from the list of baud rates (bps).
Example: xConfiguration SerialPort BaudRate: 38400
xConfiguration SerialPort LoginRequired
The Serial Login setting determines whether or not there should be a login when connecting to the COM 1
port at the codec.
Value space: <On/Off>
On: Login is required when connecting to the codec through COM port.
Off: The user can access the codec through COM port without any login.
Example: xConfiguration SerialPort LoginRequired: On
D14642.02—MAY 2010
xConfiguration
About the API About the API xConfiguration xConfiguration xCommand xCommand xStatus xStatus
The SIP settings
xConfiguration SIP Profile [1..1] Authentication [1..1] LoginName
This is the user name part of the credentials used to authenticate towards the SIP proxy.
Value space: <S: 0, 50>
Format: String with a maximum of 50 characters.
Example: xConfiguration SIP Profile 1 Authentication 1 LoginName: ""
xConfiguration SIP Profile [1..1] Authentication [1..1] Password
This is the password part of the credentials used to authenticate towards the SIP proxy.
Value space: <S: 0, 50>
Format: String with a maximum of 50 characters.
Example: xConfiguration SIP Profile 1 Authentication 1 Password:
xConfiguration SIP Profile [1..1] DefaultTransport
Select the transport protocol to be used over the LAN.
Value space: <UDP/TCP/TLS/Auto>
UDP: The system will always use UDP as the default transport method.
TCP: The system will always use TCP as the default transport method.
TLS: The system will always use TLS as the default transport method. For TLS connections a SIP
CA-list can be uploaded using the web interface. If no such CA-list is available on the system then
anonymous Diffie Hellman will be used.
Auto: The system will try to connect using transport protocols in the following order: TLS, TCP, UDP.
Example: xConfiguration SIP Profile 1 DefaultTransport: Auto
xConfiguration SIP Profile [1..1] Outbound
The client initiated connections mechanism for firewall traversal, connection reuse and redundancy. The
current version supports http://tools.ietf.org/html/draft-ietf-sip-outbound-20.
Value space: <On/Off>
On: Set up multiple outbound connections to servers in the Proxy Address list.
Off: Connect to the single proxy configured first in Proxy Address list.
Example: xConfiguration SIP Profile 1 Outbound: Off
