TANDBERG Codec C60 and Codec C40
Contents Contents Introduction Introduction
The HTTP Feedback status,
cont...
xStatus HttpFeedback [1..3] Expression
Shows the feedback from the HTTP server. There can be up to 15 expressions for each URL. See the
xCommand HttpFeedback commands for more information.
Value space of the result returned:
<S: 0..256>
Example:
xStatus HttpFeedback 3 Expression
*s HttpFeedback 3 Expression: "/History/CallLog/History"
*s HttpFeedback 3 Expression: "/Status/Call[Status='connected']"
*s HttpFeedback 3 Expression: "/Status/H323/Gatekeeper"
*s HttpFeedback 3 Expression: "/Status/Ethernet"
*s HttpFeedback 3 Expression: "/Event/CallSuccessful"
*s HttpFeedback 3 Expression: ""
*s HttpFeedback 3 Expression: ""
*s HttpFeedback 3 Expression: ""
*s HttpFeedback 3 Expression: ""
*s HttpFeedback 3 Expression: ""
*s HttpFeedback 3 Expression: ""
*s HttpFeedback 3 Expression: ""
*s HttpFeedback 3 Expression: ""
*s HttpFeedback 3 Expression: ""
*s HttpFeedback 3 Expression: ""
** end
D14642.02—MAY 2010
About the API About the API xConfiguration xConfiguration
xStatus
xCommand xCommand xStatus xStatus
The Media Channel status
xStatus MediaChannel
Shows the top level overview of the media channel status. The example shows the status for an ongoing
call. The identities of the call and channels are used when querying additional information.
Example:
xStatus Media
*s MediaChannels Call 27 IncomingAudioChannel 327 Encryption Status: On
*s MediaChannels Call 27 IncomingAudioChannel 327 Audio Protocol: AACLD
*s MediaChannels Call 27 IncomingAudioChannel 327 Audio Mute: True
*s MediaChannels Call 27 IncomingAudioChannel 327 Audio Channels: 1
*s MediaChannels Call 27 IncomingVideoChannel 330 Encryption Status: On
*s MediaChannels Call 27 IncomingVideoChannel 330 ChannelRole: Main
*s MediaChannels Call 27 IncomingVideoChannel 330 Video Protocol: H264
*s MediaChannels Call 27 IncomingVideoChannel 330 Video FrameRate: 25
*s MediaChannels Call 27 IncomingVideoChannel 330 Video ResolutionX: 352
*s MediaChannels Call 27 IncomingVideoChannel 330 Video ResolutionY: 288
*s MediaChannels Call 27 IncomingVideoChannel 333 Encryption Status: Off
*s MediaChannels Call 27 IncomingVideoChannel 333 ChannelRole: Presentation
*s MediaChannels Call 27 IncomingVideoChannel 333 Video Protocol: Off
*s MediaChannels Call 27 IncomingVideoChannel 333 Video FrameRate: 0
*s MediaChannels Call 27 IncomingVideoChannel 333 Video ResolutionX: 0
*s MediaChannels Call 27 IncomingVideoChannel 333 Video ResolutionY: 0
*s MediaChannels Call 27 OutgoingAudioChannel 328 Encryption Status: On
*s MediaChannels Call 27 OutgoingAudioChannel 328 Audio Protocol: AACLD
*s MediaChannels Call 27 OutgoingAudioChannel 328 Audio Channels: 1
*s MediaChannels Call 27 OutgoingVideoChannel 331 Encryption Status: On
*s MediaChannels Call 27 OutgoingVideoChannel 331 ChannelRole: Main
*s MediaChannels Call 27 OutgoingVideoChannel 331 Video Protocol: H264
*s MediaChannels Call 27 OutgoingVideoChannel 331 Video FrameRate: 30
*s MediaChannels Call 27 OutgoingVideoChannel 331 Video ResolutionX: 1024
*s MediaChannels Call 27 OutgoingVideoChannel 331 Video ResolutionY: 576
*s MediaChannels Call 27 OutgoingVideoChannel 334 Encryption Status: Off
*s MediaChannels Call 27 OutgoingVideoChannel 334 ChannelRole: Presentation
*s MediaChannels Call 27 OutgoingVideoChannel 334 Video Protocol: Off
*s MediaChannels Call 27 OutgoingVideoChannel 334 Video FrameRate: 0
*s MediaChannels Call 27 OutgoingVideoChannel 334 Video ResolutionX: 0
*s MediaChannels Call 27 OutgoingVideoChannel 334 Video ResolutionY: 0
** end
