The SIP status
xStatus SIP
Shows the top level overview of the SIP status.
Value space of the result returned:
<N/A>
Example:
xStatus SIP
*s SIP Proxy 1 Status: Active
*s SIP Proxy 1 Address: "192.0.2.50"
*s SIP Proxy 1 Secure: True
*s SIP Proxy 1 Verified: False
*s SIP Registration 1 Status: Registered
*s SIP Registration 1 Reason: ""
*s SIP Registration 1 URI: "firstname.lastname@company.com"
*s SIP Registration 1 Authentication: Off
*s SIP Profile 1 Proxy 1 Status: Active
*s SIP Profile 1 Proxy 1 Address: "192.0.2.50"
*s SIP Profile 1 Secure: True
*s SIP Profile 1 Verified: False
*s SIP Profile 1 Authentication: Off
*s SIP Profile 1 Registration 1 Status: Registered
*s SIP Profile 1 Registration 1 Reason: ""
*s SIP Profile 1 Registration 1 URI: "firstname.lastname@company.com"
** end
D14642.02—MAY 2010
About the API About the API xConfiguration xConfiguration
xStatus
xCommand xCommand xStatus xStatus
The SIP status,
cont...
xStatus SIP Proxy 1 Status
Shows the status of the communication between the endpoint and the SIP Proxy server.
Active: The communication between the endpoint and the SIP Proxy is active.
DNSFailed: The attempt to establish communication to the DNS server failed.
Off: There is no communication between the endpoint and the SIP Proxy.
Timeout: The attempt to establish communication to the SIP Proxy timed out.
UnableTCP: The system is unable to use TCP as the transport method.
UnableTLS: The system is unable to use TLS as the transport method.
Unknown: The status of the communication is not known.
Value space of the result returned:
<Active/DNSFailed/Off/Timeout/UnableTCP/UnableTLS/Unknown>
Example:
xStatus SIP Proxy 1 Status
*s SIP Proxy 1 Status: Active
** end
xStatus SIP Proxy 1 Address
Shows the address of the SIP Proxy that the system communicates with.
Value space of the result returned:
<S: 0, 255>
Example:
xStatus SIP Proxy 1 Address
*s SIP Proxy 1 Address: "192.0.2.50"
** end
xStatus SIP Proxy 1 Secure
Shows the encryption status of the signalling with the SIP Proxy server.
Value space of the result returned:
<True/False>
Example:
xStatus SIP Proxy 1 Secure
*s SIP Proxy 1 Secure: True
** end
