The Video settings,
continued...
xConfiguration Video OSD Output
The Video OSD (On Screen Display) Output lets you define which monitor should display the on screen
menus, information and icons. By default the OSD is sent to the monitor connected to the Video OSD
Output 1. If you cannot see the OSD on screen, then you must re-configure the OSD Output. You can
do this by entering a key sequence on the remote control, from the web interface, or by a command line
interface.
Using the TANDBERG Remote Control TRC5: Press the Disconnect key followed by: * # * # 0 x # (where x
is output 1 to 2).
Using the web interface: Open a web browser and enter the IP address of the codec. Open the Advanced
menu and navigate to Video OSD Output and select the video output.
Using a command line interface: Open a command line interface and connect to the codec (if in doubt of
how to do this, see the API Guide for the codec). Enter the command: xConfiguration Video OSD Output
[1..2] (select the OSD Output).
Value space: <1..2>
Range: Select 1 for HDMI 1 output, or select 2 for DVI-I 2 output.
Example: xConfiguration Video OSD Output: 1
xConfiguration Video OSD TodaysBookings
This setting can be used to display the systems bookings for today on the main OSD menu. This requires
that the system is bookable by an external booking system, like TMS (TANDBERG Management Suite).
Value space: <On/Off>
On: Displays information about this systems bookings on screen.
Off: Do not display todays bookings.
Example: xConfiguration Video OSD TodaysBookings: Off
xConfiguration Video OSD MyContactsExpanded
Set how the local contacts will be displayed in the phone book dialog in the OSD (On Screen Display).
Value space: <On/Off>
On: The local contacts in the phone book will be shown in the top level of the phonebook dialog.
Off: The local contacts will be placed in a separate folder called MyContacts in the phonebook dialog.
Example: xConfiguration Video OSD MyContactsExpanded: Off
D14642.02—MAY 2010
xConfiguration
About the API About the API xConfiguration xConfiguration xCommand xCommand xStatus xStatus
The Video settings,
continued...
xConfiguration Video Output HDMI [1] MonitorRole
The HDMI monitor role describes what video stream will be shown on the monitor connected to the video
output HDMI connector. Applicable only if the "Video > Monitors" configuration is set to dual.
Value space: <First/Second/PresentationOnly>
First: Show main video stream.
Second: Show presentation video stream if active, or other participants.
PresentationOnly: Show presentation video stream if active, and nothing else.
Example: xConfiguration Video Output HDMI 1 MonitorRole: First
xConfiguration Video Output HDMI [1] OverscanLevel
Some TV's or other monitors may not display the whole image sent out on the systems video output, but
cuts the outer parts of the image. In this case this setting can be used to let the system not use the outer
parts of video resolution. Both the video and the OSD menu will be scaled in this case.
Value space: <Medium/High/None>
Medium: The system will not use the outer 3% of the output resolution.
High: The system will not use the outer 6% of the output resolution
None: The system will use all of the output resolution.
Example: xConfiguration Video Output HDMI 1 OverscanLevel: None
xConfiguration Video Output HDMI [1] Resolution
Select the preferred resolution for the monitor connected to the video output HDMI connector. This will
force the resolution on the monitor.
Value space: <Auto/640_480_60/800_600_60/1024_768_60/1280_1024_60/1280_720_60/1920_1080_
60/1280_768_60/1360_768_60/1366_768_60/1600_1200_60/1920_1200_60>
Auto: The system will automatically try to set the optimal resolution based on negotiation with the
connected monitor.
Range: 640x480@60p, 800x600@60p, 1024x768@60p, 1280x1024@60p, 1280x720@60p,
1920x1080@60p, 1280x768@60p, 1360x768@60p, 1366x768@60p, 1600x1200@60p,
1920x1200@60p
Example: xConfiguration Video Output HDMI 1 Resolution: 1920 _ 1080 _ 60
