The Camera settings,
continued...
xConfiguration Cameras Camera [1..7] IrSensor
The IR sensor LED is located in the front of the camera and flickers when the IR sensor is activated from
the remote control. Both the TANDBERG camera and codec has an IR sensor. You would normally choose
just one of them to be active at a time.
Value space: <On/Off>
On: Enable the IR sensor on the camera.
Off: Disable the IR sensor on the camera.
Example: xConfiguration Cameras Camera 1 IrSensor: On
xConfiguration Cameras Camera [1..7] Mirror
With Mirror mode (horizontal flip) you can mirror the image on screen.
Value space: <Auto/On/Off>
Auto: When the camera is placed upside down the image is automatically mirrored. Use this setting
with cameras that can be mounted upside down, and that can auto detect that the camera is mounted
upside down.
On: See the selfview in mirror mode, e.g. the selfview is reversed and the experience of selfview is as
seeing yourself in a mirror.
Off: See the selfview in normal mode, e.g. the experience of selfview is as seeing yourself as other
people see you.
Example: xConfiguration Cameras Camera 1 Mirror: Off
xConfiguration Cameras Camera [1..7] Whitebalance Mode
Define whether to control the camera whitebalance manually or to have it automatically adjusted by the
system.
Value space: <Auto/Manual>
Auto: When set to Auto, the camera will continuously adjust the whitebalance depending on the
camera view.
Manual: Set to Manual to enable manual control of the camera whitebalance, e.g. the level of the
whitebalance level setting will be used for the camera.
Example: xConfiguration Cameras Camera 1 Whitebalance Mode: auto
D14642.02—MAY 2010
xConfiguration
About the API About the API xConfiguration xConfiguration xCommand xCommand xStatus xStatus
The Camera settings,
continued...
xConfiguration Cameras Camera [1..7] Whitebalance Level
Set the whitebalance level. NOTE! Requires the Whitebalance Mode to be set to manual.
Value space: <1..16>
Range: Select a value from 1 to 16.
Example: xConfiguration Cameras Camera 1 Whitebalance Level: 1
xConfiguration Cameras Camera [1..7] DHCP
Applies to cameras which supports DHCP. The TANDBERG PrecsisionHD 1080p camera supports DHCP.
The camera must be connected to a LAN. When set, the command enables support for SW upgrade of
daisy chained cameras. It will enable the camera's DHCP function and force start of MAC and IP address
retrieval. Remember to reset the DHCP when the camera is no longer connected to a LAN.
Value space: <On/Off>
On: Enable DHCP in the camera. The camera is automatically re-booted. After re-boot the DHCP is
started and the IP address will be retrieved. Run the commnand "xStatus Camera" for result.
Off: Disable DHCP in the camera. NOTE! When camera is not connected to a LAN, this setting should
be applied.
Example: xConfiguration Cameras Camera 1 DHCP: Off
