Description of the xConfiguration commands
In the following pages you will find a complete list of the xConfiguration commands. The examples
shows either the default value or an example of a value.
We recommend you visit the TANDBERG web site regularly for updated versions of the manual.
Go to: http://www.tandberg.com/docs
The Audio settings
xConfiguration Audio Input HDMI [2] Level
Define the audio level of the HDMI input connector, in steps of 1dB.
See the Audio Level tables in the physical interfaces guide for the codec for a complete overview of the
menu values represented in dB.
Value space: <-24..0>
Range: Select a value from -24 to 0dB.
Example: xConfiguration Audio Input HDMI 2 Level: 0
xConfiguration Audio Input HDMI [2] Mode
Determines whether or not the audio channels on the HDMI input should be enabled. The HDMI input 2
has two audio channels.
Value space: <On/Off>
On: Enable the audio channels on the HDMI input.
Off: Disable the audio channels on the HDMI input.
Example: xConfiguration Audio Input HDMI 2 Mode: On
xConfiguration Audio Input HDMI [2] VideoAssociation MuteOnInactiveVideo
Enable association of a video source to a HDMI audio input.
Value space: <On/Off>
On: A video source is associated, and the audio will be muted if the associated video source is not
displayed.
Off: No video source is associated.
Example: xConfiguration Audio Input HDMI 2 VideoAssociation MuteOnInactiveVideo:
Off
D14642.02—MAY 2010
xConfiguration
About the API About the API xConfiguration xConfiguration xCommand xCommand xStatus xStatus
The Audio settings,
continued...
xConfiguration Audio Input HDMI [2] VideoAssociation VideoInputSource
Select the associated video input source.
Value space: <1/2/3>
Range: Select one of the three video input sources.
Example: xConfiguration Audio Input HDMI 2 VideoAssociation VideoInputSource: 1
xConfiguration Audio Input Line [1..2] Equalizer ID
Select the audio input line equalizer ID.
Value space: <1..8>
Range: Select Equalizer ID 1 to 8.
Example: xConfiguration Audio Input Line 1 Equalizer ID: 1
xConfiguration Audio Input Line [1..2] Equalizer Mode
Set the audio input line equalizer mode.
Value space: <On/Off>
On: Enable the equalizer for the audio input line.
Off: No equalizer.
Example: xConfiguration Audio Input Line 1 Equalizer Mode: Off
xConfiguration Audio Input Line [1..2] VideoAssociation MuteOnInactiveVideo
Enable association of a video source to a Line audio input.
Value space: <On/Off>
On: A video source is associated, and the audio will be muted if the associated video source is not
displayed.
Off: No video source is associated.
Example: xConfiguration Audio Input Line 1 VideoAssociation MuteOnInactiveVideo:
Off
xConfiguration Audio Input Line [1..2] VideoAssociation VideoInputSource
Select the associated video input source.
Value space: <1/2/3>
Range: Select one of the three video input sources.
Example: xConfiguration Audio Input Line 1 VideoAssociation VideoInputSource: 1
