xCommand operations
Command type commands are used to instruct
the system to perform a given action.
Return result parameters
The following operations can be performed on
xCommand:
Command Help
• *h is used when returning the result of a
query
Command Write
• *r is used when returning the result of a
command
D14642.02—MAY 2010
About the API
About the API About the API
xCommand Help
To get help on a setting you can use a help
query. Enter the path followed by ? or help.
•
xCommand dial ?
Returns a set of return values. See the
example to the right.
•
xCommand dial help
As above.
help
write
xCommand Write
When issuing a command, the system will return
a set of return values. The structure is described
by the example to the right.
•
xCommand Dial Number: 12345
Issues the command and gives a response.
See the example to the right.
The response will by default be on the same
format as the standard XACLI Status format.
The XML status format is also supported.
You can read more about XML in the
xPreferences section.
xConfiguration xConfiguration xCommand xCommand
Example with xCommand Help
To get help on xCommand, type
xCommand <address expression> ?
xCommand Dial ?
*h xCommand Dial
Number(r): <S: 0, 255>
Protocol: <H323/Sip>
CallRate: <64..6000>
CallType: <Audio/Video>
ForceNewConference: <False/True>
ConferenceId: <0..65534>
OK
Example with xCommand Write
Dial a number with only the required parameter:
xCommand Dial Number: 95458458
OK
*r DialResult (status=OK):
CallId: 2
ConferenceId: 1
*r/end
OK
19
xStatus xStatus Appendices Appendices
? or help after the command path (address expression):
