TANDBERG Codec C60 and Codec C40
Contents Contents Introduction Introduction
Remote Control TRC5–
Key map
The TANDBERG Remote control TRC5 has
the following button codes and IR signal
parameters.
You will find a one page overview of the
TANDBERG Remote Control TRC5 overleaf.
D14642.02—MAY 2010
About the API About the API xConfiguration xConfiguration
Button codes - Remote control TRC5
Dec Hex Address Button name
0 0
1 1 0 Number 1
2 2 0 Number 2
3 3 0 Number 3
4 4 0 Number 4
5 5 0 Number 5
6 6 0 Number 6
7 7 0 Number 7
8 8 0 Number 8
9 9 0 Number 9
10 0A 0 Number 0
11 0B 0 *
12 0C 0 #
13 0D
14 0E
15 0F
16 10
17 11 0 Presenter
18 12
19 13
20 14
21 15
22 16 0 Zoom out
23 17 0 Zoom in
24 18
25 19 0 Volume down
26 1A 0 Volume up
27 1B 0 Microphone off
28 1C
29 1D 0 Arrow up
30 1E 0 Arrow down
31 1F 0 Arrow left
32 20 0 Arrow right
xCommand xCommand xStatus xStatus
Button codes - Remote control TRC5
Dec Hex Address Button name
33 21 0 Ok
34 22 0 Call
35 23 0 End call
36 24 0 Phone book
37 25 0 Layout
38 26 0 Clear
39 27
– –
41 29
42 2A 0 Soft key 1
43 2B 0 Soft key 2
44 2C 0 Soft key 3
45 2D 0 Soft key 4
46 2E 0 Soft key 5
– –
– –
– –
– –
51 33 0 Home
143
API Guide
Appendices
Appendices Appendices Contact us Contact us
IR Signal parameters
Name Description
Protocol Siemens SDA2208
Reference frequency 485 kHz
Address 4 and 7
IR wavelength 940 nm
IR carrier frequency 30 kHz
