The Network settings,
continued...
xConfiguration Network [1..1] IPv4 SubnetMask
Define the IP network subnet mask. Only applicable if the Network Assignment is set to Static.
Value space: <S: 0, 64>
Format: Compact string with a maximum of 64 characters.
Example: xConfiguration Network 1 IPv4 SubnetMask: "255.255.255.0"
xConfiguration Network [1..1] IPv4 QoS Mode
The QoS (Quality of Service) is a method which handles the priority of audio, video and data in the
network. The QoS settings must be supported by the infrastructure. Diffserv (Differentiated Services) is
a computer networking architecture that specifies a simple, scalable and coarse-grained mechanism for
classifying, managing network traffic and providing QoS priorities on modern IP networks.
Value space: <Off/Diffserv>
Off: No QoS method is used.
Diffserv: When you set the QoS Mode to Diffserv you must configure the Diffserv sub menu settings
(Audio, Data, Signalling and Video).
Example: xConfiguration Network 1 IPv4 QoS Mode: diffserv
xConfiguration Network [1..1] IPv4 QoS Diffserv Audio
The Diffserv Audio defines which priority Audio packets should have in an IP network. Enter a priority,
which ranges from 0 to 63 for the packets. The higher the number, the higher the priority. These priorities
might be overridden when packets are leaving the network controlled by the local network administrator.
NOTE! Requires the Network IPv4 QoS Mode to be set to Diffserv.
Value space: <0..63>
Audio: A recommended value is Diffserv Code Point (DSCP) is AF41, which equals the value 34. If in
doubt, contact your network administrator.
Example: xConfiguration Network 1 IPv4 QoS Diffserv Audio: 0
xConfiguration Network [1..1] IPv4 QoS Diffserv Data
The Diffserv Data defines which priority Data packets should have in an IP network. Enter a priority, which
ranges from 0 to 63 for the packets. The higher the number, the higher the priority. These priorities might
be overridden when packets are leaving the network controlled by the local network administrator. NOTE!
Requires the Network IPv4 QoS Mode to be set to Diffserv.
Value space: <0..63>
Data: A recommended value is Diffserv Code Point (DSCP) AF23, which equals the value 22. If in
doubt, contact your network administrator.
Example: xConfiguration Network 1 IPv4 QoS Diffserv Data: 0
D14642.02—MAY 2010
xConfiguration
About the API About the API xConfiguration xConfiguration xCommand xCommand xStatus xStatus
The Network settings,
continued...
xConfiguration Network [1..1] IPv4 QoS Diffserv Signalling
The Diffserv Signalling defines which priority Signalling packets should have in an IP network. Enter a
priority, which ranges from 0 to 63 for the packets. The higher the number, the higher the priority. These
priorities might be overridden when packets are leaving the network controlled by the local network
administrator. NOTE! Requires the Network IPv4 QoS Mode to be set to Diffserv.
Value space: <0..63>
Signalling: A recommended value is Diffserv Code Point (DSCP) AF31, which equals the value 26. If in
doubt, contact your network administrator.
Example: xConfiguration Network 1 IPv4 QoS Diffserv Signalling: 0
xConfiguration Network [1..1] IPv4 QoS Diffserv Video
The Diffserv Video defines which priority Video packets should have in an IP network. Enter a priority,
which ranges from 0 to 63 for the packets. The higher the number, the higher the priority. These priorities
might be overridden when packets are leaving the network controlled by the local network administrator.
NOTE! Requires the Network IPv4 QoS Mode to be set to Diffserv.
Value space: <0..63>
Video: A recommended value is Diffserv Code Point (DSCP) AF41, which equals the value 34. If in
doubt, contact your network administrator.
Example: xConfiguration Network 1 IPv4 QoS Diffserv Video: 0
xConfiguration Network [1..1] IEEE8021X Mode
The system can be connected to an IEEE 802.1X LAN network, with a port-based network access control
that is used to provide authenticated network access for Ethernet networks.
Value space: <On/Off>
On: The 802.1X authentication is enabled.
Off: The 802.1X authentication is disabled (default).
Example: xConfiguration Network 1 IEEE8021X Mode: Off
xConfiguration Network [1..1] IEEE8021X Identity
The 802.1X Identity is the user name needed for 802.1X authentication.
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: xConfiguration Network 1 IEEE8021X Identity: ""
