The Camera commands,
cont...
xCommand Camera Ramp
Move the camera in a specified direction. The camera will move at specified speed until a stop command
is issued. In a daisy chain, you need to know the CameraId for the camera you want to address. NOTE!
You must run a stop command to stop the camera, see the example below.
CameraId: Give the camera id.
Pan: Move the camera to the Left or Right, followed by Stop.
PanSpeed: Set the pan speeed.
Tilt: Move the camera Up or Down, followed by Stop.
TiltSpeed: Set the tilt speeed.
Zoom: Zoom the camera In or Out, followed by Stop.
ZoomSpeed: Set the zoom speeed.
Focus: Focus the camera Far or Near, followed by Stop.
Parameters:
CameraId(r): <1..7>
Pan: <Left/Right/Stop>
PanSpeed: <1..15>
Tilt: <Down/Stop/Up>
TiltSpeed: <1..15>
Zoom: <In/Out/Stop>
ZoomSpeed: <1..15>
Focus: <Far/Near/Stop>
Example:
xCommand Camera Ramp CameraId:1 Pan:left PanSpeed:1
OK
*r RampResult (status=OK):
** endxCommand Camera Ramp CameraId:1 Pan:stop
OK
*r RampResult (status=OK):
** end
D14642.02—MAY 2010
About the API About the API xConfiguration xConfiguration
xCommand
xCommand xCommand xStatus xStatus
The Camera commands,
cont...
xCommand Camera TriggerAutofocus
Trigger the autofocus functionality. The camera must support autofocus functionality. In a daisy chain you
need to know the CameraId for the camera you want to address.
Parameters:
CameraId(r): <1..7>
Example:
xCommand Camera TriggerAutofocus CameraId:1
OK
*r TriggerAutofocusResult (status=OK):
** end
xCommand Camera ReconfigureCameraChain
Reinitialize the daisy chain of cameras and updates the CameraId parameter. The CameraId parameter
holds information of which camera is sitting in what position in the camera chain.
Parameters:
No paramters.
Example:
xCommand Camera ReconfigureCameraChain
*r ReconfigureCameraChainResult (status=OK):
** end
