The Video settings,
continued...
xConfiguration Video Output DVI [2] MonitorRole
The DVI monitor role describes what video stream will be shown on the monitor connected to the video
output DVI-I connector. Applicable only if the "Video > Monitors" configuration is set to dual.
Value space: <First/Second/PresentationOnly>
First: Show main video stream.
Second: Show presentation video stream if active, or other participants.
PresentationOnly: Show presentation video stream if active, and nothing else.
Example: xConfiguration Video Output DVI 2 MonitorRole: Second
xConfiguration Video Output DVI [2] OverscanLevel
Some TV's or other monitors may not display the whole image sent out on the systems video output, but
cuts the outer parts of the image. In this case this setting can be used to let the system not use the outer
parts of video resolution. Both the video and the OSD menu will be scaled in this case.
Value space: <Medium/High/None>
Medium: The system will not use the outer 3% of the output resolution.
High: The system will not use the outer 6% of the output resolution
None: The system will use all of the output resolution.
Example: xConfiguration Video Output DVI 2 OverscanLevel: None
xConfiguration Video Output DVI [2] Resolution
Select the preferred resolution for the monitor connected to the video output DVI-I connector. This will
force the resolution on the monitor.
Value space: <Auto/640_480_60/800_600_60/1024_768_60/1280_1024_60/1280_720_60/1920_1080_
60/1280_768_60/1360_768_60/1366_768_60/1600_1200_60/1920_1200_60>
Auto: The system will automatically try to set the optimal resolution based on negotiation with the
connected monitor.
Range: 640x480@60p, 800x600@60p, 1024x768@60p, 1280x1024@60p, 1280x720@60p,
1920x1080@60p, 1280x768@60p, 1360x768@60p, 1366x768@60p, 1600x1200@60p,
1920x1200@60p
Example: xConfiguration Video Output DVI 2 Resolution: 1024 _ 768 _ 60
D14642.02—MAY 2010
xConfiguration
About the API About the API xConfiguration xConfiguration xCommand xCommand xStatus xStatus
The Video settings,
continued...
xConfiguration Video Output Composite [3] MonitorRole
NOTE! This command is not supported on Codec C40.
The Composite monitor role describes what video stream will be shown on the monitor connected to the
video output Composite connector. Applicable only if the monitor configuration is set to dual.
Value space: <First/Second/PresentationOnly>
First: Show main video stream.
Second: Show presentation video stream if active, or other participants.
PresentationOnly: Show presentation video stream if active, and nothing else.
Example: xConfiguration Video Output Composite 3 MonitorRole: First
xConfiguration Video Output Composite [3] OverscanLevel
NOTE! This command is not supported on Codec C40.
Some TV's or other monitors may not display the whole image sent out on the systems video output, but
cuts the outer parts of the image. In this case this setting can be used to let the system not use the outer
parts of video resolution. Both the video and the OSD menu will be scaled in this case.
Value space: <Medium/High/None>
Medium: The system will not use the outer 3% of the output resolution.
High: The system will not use the outer 6% of the output resolution
None: The system will use all of the output resolution.
Example: xConfiguration Video Output Composite 3 OverscanLevel: None
xConfiguration Video Output Composite [3] Resolution
NOTE! This command is not supported on Codec C40.
Select the preferred resolution for the monitor connected to the video output Composite connector. This
will force the resolution on the monitor.
Value space: <PAL/NTSC>
Range: Select PAL or NTSC resoultion.
Example: xConfiguration Video Output Composite 3 Resolution: NTSC
