TANDBERG Codec C60 and Codec C40
Contents Contents Introduction Introduction
About xConfiguration
The xConfiguration type commands defines the system settings
and are either supplied or read by the user. The xConfigurations
commands are organized in a hierarchic tree structure.
To get an overview of accessible top-level configuration elements
within the xConfiguration commands, enter
xConfiguration command:
•
xConfiguration ?
•
xConfiguration help
To get an overview of all supported xConfiguration commands
with the corresponding value space, enter
xConfiguration command:
•
xConfiguration ??
When issuing a xConfiguration command, the command consists
of three parts:
1. The type of command: xConfiguration
2. The path: An address expression, terminated by a colon
3. The value: A value type
Example: xConfiguration Audio Input HDMI 1 Mode:
The type The path
D14642.02—MAY 2010
About the API
About the API About the API
xConfiguration ?
– User Configurations –
Audio
Cameras
Conference
? or help after the
Experimental
OK
?? after the
xConfiguration ??
*h xConfiguration Audio Volume: <0..100>
Sets the volume level [0-100] on the loudspeaker output in steps of 0.5dB from -34.5dB to 15dB.
*h xConfiguration Audio Input Microphone [1..8] Type: <Microphone/Line>
On
The microphone inputs are intended for electret type microphones. The microphone inputs are
The value
*h xConfiguration Audio Input Microphone [1..8] Mode: <On/Off>
By default, all inputs are enabled. Just plug in an audio source and it is active. Audio inputs
.
.
.
OK
xConfiguration xConfiguration xCommand xCommand
GPIO
H323
Network
NetworkServices
Volume 0 = Off. The volume level bar which is displayed on screen, when using the
remote control, goes from 0 to 20. Range: The volume level goes from 0 to 100. Volum
level equals Audio gain value
equals 15.0 dB
balanced with 48 V phantom power. The microphone input can be set to line or
microphone mode. Addresses the specific microphone. Microphone: Phantom voltage and
pre-amplification is On. Line: Select Line when you have a standard balanced line
input. The phantom voltage and pre-amplification is Off.
that are On will automatically be mixed. Unconnected inputs will automatically be
muted. Addresses the specific microphone. On: Turns the microphone On. Off: Connected
but unused inputs should be set to Off to prevent audio/noise from the inputs.
16
xStatus xStatus Appendices Appendices
Phonebook
Provisioning
SerialPort
SIP
0 equals 0 1 equals -34.5 dB 70 equals 0.0 dB
API Guide
Contact us Contact us
Standby
SystemUnit
Time
Video
100
