The Audio settings,
continued...
xConfiguration Audio Input Line [1..2] Channel
Define whether the Audio Line input is a mono signal or part of a multichannel signal.
Value space: <Left/Right/Mono>
Left: The Audio Line input signal is the left channel of a stereo signal.
Right: The Audio Line input signal is the right channel of a stereo signal.
Mono: The Audio Line input signal is a mono signal.
Example: xConfiguration Audio Input 1 Channel: Left
xConfiguration Audio Input Line [1..2] Level
Define the audio level of the Line input connector, in steps of 1dB.
See the Audio Level tabels in the physical interfaces guide for the codec for a complete overview of the
values represented in dB.
Value space: <0..24>
Range: Select a value from 0 to 24dB.
Example: xConfiguration Audio Input Line 1 Level: 10
xConfiguration Audio Input Line [1..2] LoopSuppression
NOTE! Codec C40/C60 does currently not support Loop Suppression, hence Loop Suppression can be
set to Off only.
Value space: <Off>
Off: Deactivate Loop Suppression.
Example: xConfiguration Audio Input Line 1 LoopSuppression: Off
xConfiguration Audio Input Line [1..2] Mode
Set the audio input line mode.
Value space: <On/Off>
On: Enable the Audio Line input.
Off: Disable the Audio Line input.
Example: xConfiguration Audio Input Line 1 Mode: On
D14642.02—MAY 2010
xConfiguration
About the API About the API xConfiguration xConfiguration xCommand xCommand xStatus xStatus
The Audio settings,
continued...
xConfiguration Audio Input Microphone [1..2]/[1..4] EchoControl Mode
NOTE! Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
The echo canceller continuously adjusts itself to the audio characteristics of the room and compensate for
any changes it detects in the audio environment. If the changes in the audio conditions are very significant
the echo canceller may take a second or two to re-adjust.
Value space: <On/Off>
On: Echo Control is normally set to On to prevent the far end from hearing their own audio. Once
selected, echo cancellation is active at all times.
Off: Echo Control should be switched Off if external echo cancellation or playback equipment is used.
Example: xConfiguration Audio Input Microphone 1 EchoControl Mode: On
xConfiguration Audio Input Microphone [1..2]/[1..4] EchoControl NoiseReduction
NOTE! Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
The system has a built-in noise reduction which reduces constant background noise (e.g. noise from
air-conditioning systems, cooling fans etc.). In addition, a high pass filter (Humfilter) reduces very low
frequency noise. NOTE! Requires the Echo Control Mode to be enabled for the microphone.
Value space: <On/Off>
On: The Noice Reduction should be enabled in the presence of low frequency noise.
Off: Turn off the Noise Reduction.
Example: xConfiguration Audio Input Microphone 1 EchoControl NoiseReduction: On
xConfiguration Audio Input Microphone [1..2]/[1..4] Equalizer ID
NOTE! Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
Select the audio input microphone equalizer ID.
Value space: <1..8>
Range: Select Equalizer ID 1 to 8.
Example: xConfiguration Audio Input Microphone 1 Equalizer ID: 1
xConfiguration Audio Input Microphone [1..2]/[1..4] Equalizer Mode
NOTE! Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
Set the audio input microphone equalizer mode.
Value space: <On/Off>
On: Enable the equalizer for the audio input microphone.
Off: No equalizer.
Example: xConfiguration Audio Input Microphone 1 Equalizer Mode: Off
