1.3.9

Packages

Package field codes are listed in Table 10. For questions about specific packages, please contact Quasonix.
Band
L or S band
L or S band
C band
C band
L/S band
L/S band
L/C, S/C, or L/S/C
band
Transmitter weight may vary depending on packages and applications. For information about the weight of a
particular transmitter, please contact Quasonix.
1.3.10 Automatic Carrier Wave Output Option — AC
This option allows the TIMTER to transmit a carrier wave when the clock input is absent, which would normally
cause the RF output to be turned off.
1.3.11 Adapter Plate – AP
Use this option to include the 2.5" x 3.5" adapter plate (hardware accessory) with the order.
1.3.12 Baud Rate Option – BRx
The BR option changes the serial communications default baud rate on the transmitter to the one selected. A number
from 0-8 follows the BR option request. Corresponding values are as follows: 0 = 57600 (Standard default for all
Quasonix transmitters); 1 = 4800; 2 = 9600; 3 = 19200; 4 = 38400; 5 = 56000; 6 = 57600; 7 = 115200, 8 = 230400.
1.3.13 CP07 Control Protocol Option – C7
The Quasonix interpretation of IRIG 106-17, Appendix 2-C serial control protocol (CP07) "provides standards for
commands, queries, and status information when communicating with telemetry transmitters configured with
communication ports." The Basic command set contains the minimum (required) commands for transmitter control,
query, and status. The Extended command set contains optional commands that may or may not be implemented at
the manufacturer's discretion. CP07 is enabled when the C7 option is requested.
The default baud rate for CP07 transmitters is 9600.
8 Quasonix, Inc.

Table 10: Package Codes

Primary TIMTER™
Connector Package
Female 07AH
MDM-15
Male 07AN
MDM-15
Female 09AK
MDM-15
Male 09AM
MDM-15
Female 18AD
MDM-15
Male 18AE
MDM-15
Contact 24xx
Quasonix
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Volume Width Length
2.000"
7.200 in 3
2.000"
3
7.200 in
2.000"
3
9.450 in
2.000"
3
9.450 in
4.000"
3
18.420 in
4.000"
3
18.420 in
4.000"
22.200 in 3
Height
3.000" 1.200"
3.000" 1.200"
3.000" 1.575"
3.000" 1.575"
3.000" 1.535"
3.000" 1.535"
3.000" 2.000"
