Mnemonic Name
Command
LP Low Power
LPE LDPC Parity
Enable
LV Digital Board
ADC Low
Voltages
52 Quasonix, Inc.
Description
Report or set low power level
when dual power option enabled
on unit
Valid range is 0-31 in 1 dB steps
or 0-31.5 in 0.5 dB steps,
depending on the transmitter
Examples:
LP Report the present low
power level
LP 3 Set low power to 3
LP Max Set low power to the
highest allowable value for the
unit
LP Min Set low power to the
minimum allowable value for the
unit
Enables the parity calculation with
Low Density Parity Check coding
Valid options are 0 and 1
Examples:
LPE Show the current LPE
state
LPE 1 Enable the parity
calculation
LPE 0 Disable the parity
calculation
Displays the digital board low
voltage ADC values
Example:
LV Show the current values
Example output:
3_SOQPSK>3.6V RF Voltage :
0.091 A
3_SOQPSK>5.5VDC Voltage
5.652 V
3_SOQPSK>1.1V Voltage
1.131 V
3_SOQPSK>3.6V Dig Voltage:
3.579 V
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s) Setting
Required Saved?
DP Y
LD Y
Standard N/A
:
:
Factory
Default
LP 0
LPE 1
N/A
