Quasonix TIMTER Installation And Operation Manual page 71

Mnemonic Name
Command
SPB Serial Port
Buffers
SS Show Settings
SV or SA Save
Configuration
64 Quasonix, Inc.
Description
Displays the serial port buffer
addresses and current pointers
Example:
SPB ?
Displays most of the common
device settings in one compact
display On in the format
SS chan
Chan = An optional channel
parameter used to override the
current channel for display
information
Valid channels are 1, 2, or 3 (to
display both)
Example:
SS 1
Saves the current transmitter
configuration to a user-selected
preset number, from 0 to 15
where 0 is the power-on default
unless hardware presets are
enabled
The SV command also allows the
user to assign an alias to the
desired preset.
Examples:
SV 1 Save current
configuration to preset 1
SV 7 xyz Save current
configuration to preset 7 and
assign alias name "xyz"
*Refer to SV Note below for
exception
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s) Setting
Required Saved?
Standard
Standard N/A
Standard N/A
Factory
Default
N/A
N/A
