Mnemonic Name
Command
CG Clock Generator
Source Select
CH Current Channel
CLKS Clock Source
CMNIO Common IO
Display
39 Quasonix, Inc.
Description
Report or set the clock generator
output source
Examples:
CG Report the clock free
state
CG 0 Clock Gen output Off
CG 1 Use DG0 Internal clock
Refer to section 4.2.3.1.1 for
additional CG command detail
Selects current channel for
commands
Valid options are:
1 Apply commands to channel 1
2 Apply commands to channel 2
3 Apply commands to both
channels
Example:
CH Report current channel
CH 1 Set current channel to 1
Refer to CS command
Displays common IO enable and
output registers
When ? entered as argument, bit
definitions for registers are listed
Example:
CMNIO ? List bit definitions
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s) Setting
Required Saved?
CG Y
Standard Y
Standard N
Standard
Factory
Default
CG 0
CH 1
CS 0
