Mnemonic Name
Command
CTRL Machine Control
Registers
DB Debug
DC Duplicate
Channel
41 Quasonix, Inc.
Description
This is a read only command;
Displays machine control
registers in the format
CTRL gens reg value
gens = 1, 2, or 3 for channel 1, 2,
or both data outputs
reg = S (Synth 0 ctrl)
T (Synth 1 ctrl)
M (Mod 0 ctrl)
N (Mod 1 ctrl)
value = 32 bit data
Examples:
CTRL ? Displays Help
Sets the gv.debug level
Each debug occupies one bit; turn
on multiple gv. debugs ORs the
bits
Examples:
DB ? Displays debug level
DB 5 Sets gv.debug level to
five
Copies settings from one channel
to another (channel 1 to channel
2 or channel 2 to channel 1)
An "are you sure?" prompt
displays before the command
runs.
Examples:
DC Copies Channel 1 to
Channel 2
DC 2 Copies Channel 2 to
Channel 1
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s) Setting
Required Saved?
Standard
Standard Y
Standard
Factory
Default
