Quasonix TIMTER Installation And Operation Manual page 67

Mnemonic Name
Command
RC Recall
Configuration
(or PP or
RL)
RF RF Output
60 Quasonix, Inc.
Description
Load a saved configuration into
the active configuration if the
configuration number entered is
valid
If the selected configuration has
no valid data or the command is
issued without a configuration
number, the transmitter is
initialized with the default data
and saved.
Valid range is 0-15
Example:
RC Load configuration 0
(default setup)
RC 3 Load configuration 3
Report or set RF output control
state
Note that there may be no RF
output, even if the software
control is set to ON. This can
happen if there is no valid clock in
use, or if the RF On/Off hardware
pin is in the OFF state.
Examples:
RF Report the RF output
state
RF 0 Set RF output OFF
RF 1 Set RF output ON
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s) Setting
Required Saved?
Standard N/A
Standard Y
Factory
Default
0
RF 1
