Band ID Band
Code
T Lower L, C, and Mid C
V S and C
(with Mid C)
W S and C, Mid C,
(with Euro Mid C)
X Mid C band
Y L and C
Z L and Euro Mid C
1.3.2

Clock and Data Interface

Clock and data interface codes are listed in Table 3.
Clock
and Data
Interface
Code
TTL — 10k ohms to ground
H
TTL — 75 ohms to ground
T
TTL — Selectable between 75 ohms to ground and 10k ohms to ground
A
TIA/EIA-422 (RS-422) — 120 ohms differential
R
TIA/EIA-422 (RS-422) — 120 ohms differential, even when unit is
B
powered off)
5 Quasonix, Inc.
Minimum Maximum
Freq
1435.5 MHz 1534.5 MHz
4400.0 MHz 4950.0 MHz
5091.0 MHz 5150.0 MHz
2200.5 MHz 2394.5 MHz
4400.0 MHz 4950.0 MHz
and
5091.0 MHz 5150.0 MHz
2200.5 MHz 2394.5 MHz
4400.0 MHz 4950.0 MHz
and
5091.0 MHz 5150.0 MHz
5150.0 MHz 5250.0 MHz
5091.0 MHz 5150.0 MHz
1435.5 MHz 1534.5 MHz
1750.0 MHz 1855.0 MHz
and
4400.0 MHz 4950.0 MHz
5091.0 MHz 5150.0 MHz
1435.5 MHz 1534.5 MHz
and
5150.0 MHz 5250.0 MHz

Table 3: Clock and Data Interface Codes

Baseband Clock and Data Interface
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Default Freq
Freq
1450.5 MHz
2370.5 MHz
and
2370.5 MHz
and
5120.0 MHz
1450.5 MHz
and
1450.5 MHz
and
Tuning Max
Steps Power
0.5 MHz 10 W
0.5 MHz 10 W
0.5 MHz 10 W
0.5 MHz 10 W
0.5 MHz 10 W
0.5 MHz 10 W
Defaults
TTL 10k ohms
TTL 75 ohms
TTL 75 ohms
422 120 ohms
422 120 ohms
