Quasonix TIMTER Installation And Operation Manual page 47

Mnemonic Name
Command
CP Clock Polarity
CR Current Preset
CS Clock Source
40 Quasonix, Inc.
Description
Report or set clock polarity
Examples:
CP Display the current clock
polarity
CP 0 Set clock polarity to
normal (NOT inverted)
CP 1 Set clock polarity to
inverted
CP A Set clock polarity to auto;
Automatically selects the most
reliable clock edge
Displays the currently loaded
preset
CR Display current preset
Report or set the clock source
Unit always reverts to CS 0
(external) at power-up
Examples:
CS Display the current clock
source
CS 0 Set clock source to
external
CS 1 Set clock source to
internal
When set to internal clock source,
the data source must also be set
to internal via the DS command in
order to have synchronous,
usable data.
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s) Setting
Required Saved?
Standard Y
Standard
Standard N
Factory
Default
CP A
CS 0
