1.3.8
RF Output Power
RF output power codes are listed in Table 9.
Part Number
Code
00
01
02
05
10
18
20
25
1.3.9
Packages
Package field codes are listed in Table 10. Detailed information for packages other than 04AB is located in the
TIMTER™ Transmitter Packages document, available at the Quasonix web site. For questions about specific
packages, please contact Quasonix.
TIMTER™ Package
02XX
04XX
05XX
06XX
07XX
08XX
09XX
*Package dimensions do not include connectors
9
Quasonix, Inc.
TIMTER™ Multi-mode Digital Telemetry Transmitter
Table 9: RF Output Power Codes
RF Output Power
10 mW (+10 dBm), ±1 dB
20 mW (+13 dBm), ±1 dB
1 watt (+30 dBm), minimum
2 watt (+33 dBm), minimum
5 watts (+37 dBm), minimum
10 watts (+40 dBm), minimum
18 watts (+42.5 dBm), minimum
20 watts (+43 dBm), minimum
25 watts (+44 dBm), minimum
Table 10: Package Codes
Volume
1.992 in
3
3
4.200 in
3
4.800 in
3
6.072 in
3
6.546 in
3
6.672 in
7.590 in
3
3
8.418 in
3
9.180 in
Width
Length
Height
2.000"
3.000"
0.332"
2.000"
3.000"
0.700"
2.000"
3.000"
0.800"
2.000"
3.000"
1.012"
2.000"
3.000"
1.091"
2.000"
3.000"
1.112"
2.200"
3.450"
1.000"
2.000"
3.450"
1.403"
2.000"
3.000"
1.530"
