Quasonix TIMTER Installation And Operation Manual page 51

Mnemonic Name
Command
DOUT Machine DOUT
Registers
DP Data Polarity
DS Data Source
44 Quasonix, Inc.
Description
This is a read only command;
Displays machine DOUT registers
in the format
DOUT chan R value
Chan is one or more of two (2)
dout blocks specified by one hex
character; each bit is one of the
blocks
DOUT 0 = 1
DOUT 1 = 2
DOUT 3 = 1 and 2
R = Register
C - Control
N - Noise
I - I Gain
Q - Q Gain
Value = 32 bit register value
Examples:
DOUT ? DOUT Help
Report or set data polarity
Examples:
DP Display the current data
polarity
DP 0 Set data polarity to
normal (NOT inverted)
DP 1 Set data polarity to
inverted
Refer to CS command
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s) Setting
Required Saved?
Standard Y
Standard N
Factory
Default
DP 0
DS 0
