6.1 RF Output
The minimum RF output power is 10 W with the RF load VSWR < 2:1 at all phase angles from 0 to 360 degrees.
6.2 Electrical Current
The electrical current drain for TIMTER™ transmitters is provided in Table 13.
Band Type
L or S band
L or S band
L/S band (4x3)
L/S band (4x3)
C band
C band
L/S band or S/C band (4x3)
L/C band or S/C band (4x3)
L/S/C band (4x3)
6.3 Environmental Specifications
TIMTER™ transmitters meet the environmental requirements shown in Table 14.
Environmental Specifications
Operating temperature (5 W per Output)
Operating temperature (10 W per Output)
Non-operating temperature (all models)
Operating humidity
Altitude
80 Quasonix, Inc.

6 Performance Specifications

Table 13: DC Input Current at Standard Input Voltage

Wattage
5 Watts per Output
10 Watts per Output
5 Watts per Output
10 Watts per Output
5 Watts per Output
10 Watts per Output
5 Watts per Output
10 Watts per Output
10 Watts per Output
Table 14: TIMTER™ Environmental Specifications
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Maximum Typical Current
Current @ 28 VDC
1.6 amps 1.3 amps
3.0 amps 2.5 amps
2.4 amps 1.9 amps
4.1 amps 3.5 amps
2.6 amps 2.1 amps
3.8 amps 3.0 amps
4.0 amps 3.4 amps
5.0 amps 4.5 amps
5.0 amps 4.5 amps
Description
-40°C to +85°C
-40°C to +70°C
-55°C to +100°C
0 to 95% (non-condensing)
Up to 100,000 ft.
