Quasonix TIMTER Installation And Operation Manual page 57

Mnemonic Name
Command
INF Information
Dump
IMP Impedance
Control
IR Read FPGA IO
Register
LC List
Configurations
50 Quasonix, Inc.
Description
INF does a large information
dump providing the results of the
following commands: SN, VE A,
RFS, SS, ZZ, ZF, ZS, ZCP, ZC,
ZR, ZY, SCP, SY, etc.
This is typically to capture the
state of the unit for debug.
Allows user to change impedance
of the clock and data inputs from
75 ohms to 10k ohms
Examples:
IMP 0 Set impedance to 10k
input
IMP 1 Set impedance to 75
ohms
Reads and displays any IO
register on the FPGA
Examples:
IR ? List some registers
IR addr Display a specific 32 bit
register address
Lists the stored configurations on
the unit
If a configuration number is
supplied, then the saved
parameters for that configuration
are displayed.
These are the same
configurations used by presets.
Valid configurations 0-15
Examples:
LC List all internal saved
configurations
LC 7 Show configuration 7
details
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s) Setting
Required Saved?
Standard
Clock/Data
interface
code of A
Standard N/A
Factory
Default
N/A
