Mnemonic
Name
Command
ZF
Show All
Options
ZS
Show Machine
State
ZX
Show Preset
Inputs
ZY
Show Connector
ZZ
Show Options
All commands generate a response of one or more lines, which indicate successful completion of the command or an
error.
After a command's response, the transmitter displays the mode name followed by the character ">" as a prompt,
which may be interpreted as meaning the radio is ready to accept new characters. If the CP07 option is enabled, only
the character ">" displays as a prompt.
*SV Note: Users may save internal clock and data in presets for bench debug use BUT
on a power up or when a hardware preset is restored, CS and DS will be forced to 0
(external clock and data). This action prevents a transmitter from powering up or
changing hardware presets and being set to internal clock and/or data. The ONLY way to
restore CS and/or DS as 1 from a saved configuration is by executing the RC command
or by having the -ID option available on the unit.
71
Quasonix, Inc.
Description
Displays all options (like ZZ)
except ZF shows all options
whether enabled or not
Displays all of the machine
registers for a specified block; if
no block is specified, blocks 0 and
1 are displayed
Block range is 0-3
Examples:
ZS
Show blocks 0 and 1
ZS 3
Show block 3
Displays the current preset inputs
on the parallel connector
Available presets depend on the
number specified for the unit
Values are PS2, PS4, PS8, or
PS16
Displays the transmitter's
baseband connector pinout with
proper gender, numbering, and
signal labeling
Valid only with standard 15-pin
transmitters
Displays the current hardware
configuration and options on the
transmitter based on the
transmitter part number
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s)
Setting
Required
Saved?
PSn
N/A
Standard
N/A
Standard
N/A
Factory
Default
N/A
N/A
N/A
