Quasonix TIMTER Installation And Operation Manual page 77

Multi-mode dual telemetry transmitter
Hide thumbs Also See for TIMTER:
Table of Contents

Advertisement

Mnemonic
Name
Command
XFRM
Machine
Transformer
Registers
ZC
Show All
Parameters
ZCP
Show Critical
Parameters
70
Quasonix, Inc.
Description
This is a read only command;
Displays the machine transformer
registers in the format
XFRM blk R value
Blk is one or more of four (4)
blocks specified by one hex
character; each bit is one of the
blocks
XFRM 0 = 1
XFRM 1 = 2
XFRM 2 = 4
XFRM 3 = 8
R = Register
C - Control
D - Delay
P - PM Scale
O- PM Offset
A - AM Scale
B - AM Offset
I - I Gain
Q - Q Gain
Value = 32 bit register value
Examples:
XFRM ?
XFRM command Help
Displays all parameters and
global variables (mainly for
Quasonix factory use)
Examples:
ZC
Show all configuration
parameters
ZC 2/C Show current parameters
for preset 2
Valid presets are 0-15; default is
0
Displays the current value of all
critical parameters
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s)
Setting
Required
Saved?
Standard
Factory
Default
N/A
