Parameters

3 Parameters
3.1 Main Menu - Operation and Display -
Group 0
Parameters related to the fundamental functions of the
adjustable frequency drive, function of the LCP buttons
and configuration of the LCP display.

3.1.1 0-0* Basic Settings

0-01 Language
Option: Function:
Defines the language to be used in the display.
[0] English
[1] Deutsch
[2] Francais
[3] Dansk
[4] Spanish
[5] Italiano
[28] Bras.port
[255] No Text
0-03 Regional Settings
Option: Function:
This parameter cannot be adjusted while the
motor is running. In order to meet the needs
for different default settings in different parts of
the world, 0-03 Regional Settings is implemented
in the adjustable frequency drive. The selected
setting influences the default setting of the
motor nominal frequency.
[0] Interna- Sets default value of 1-23 Motor Frequency [50
tional Hz].
[1] North Sets the default value of 1-23 Motor Frequency
America to 60 Hz.
0-04 Operating State at Power-up
Option: Function:
Select the operating mode upon reconnection of
the adjustable frequency drive to AC line voltage
after power-down when operating in Hand (local)
mode.
[0] Resume Resumes operation of the adjustable frequency
drive maintaining the same local reference and
the same start/stop condition (applied by [Hand
On]/[Off] on the LCP or Hand Start via a digital
®
VLT HVAC Basic Drive Programming Guide
0-04 Operating State at Power-up
Option:
[1] Forced
0-06 GridType
Option:
[0]
[1]
[2]
[10]
[11]
[12]
[20]
[21]
[22]
[30]
[31]
[32]
[100] 200-240V/60Hz/IT-grid
[101] 200-240V/60Hz/Delta
[102] 200-240V/60Hz
[110] 380-440V/60Hz/IT-grid
[111] 380-440V/60Hz/Delta
[112] 380-440V/60Hz
®
MG18B222 - VLT is a registered Danfoss trademark
Function:
input as before the adjustable frequency drive
was powered down).
Uses saved reference [1] to stop the adjustable
stop, frequency drive but at the same time retains the
ref=old local speed reference in memory prior to power-
down. After AC line voltage is reconnected and
after receiving a start command (using the LCP
[Hand On] button or Hand Start command via a
digital input) the adjustable frequency drive
restarts and operates at the retained speed
reference.
Function:
Select the grid type of the supply
voltage/frequency.
NOTE!
Not all choices are supported in
all power sizes.
The IT grid is a line power source
where there are no connections to
ground.
Delta is a line power source where
the secondary part of the
transformer is delta connected and
one phase is connected to ground.
200-240V/50Hz/IT-grid
200-240V/50Hz/Delta
200-240V/50Hz
380-440V/50Hz/IT-grid
380-440V/50Hz/Delta
380-440V/50Hz
440-480V/50Hz/IT-grid
440-480V/50Hz/Delta
440-480V/50Hz
525-600V/50Hz/IT-grid
525-600V/50Hz/Delta
525-600V/50Hz
