How to Program
No & Name Range
3-41 Ramp 1 0.05–3,600.0 s
Ramp Up
Time
3-42 Ramp 1 0.05–3,600.0 s
Ramp Down
Time
4-12 Motor 0.0–400 Hz
Speed Low
Limit [Hz]
4-14 Motor 0.0–400 Hz
Speed High
Limit [Hz]
4-19 Max 0–400
Output
Frequency
Table 2.6
Changes Made
Changes Made lists all parameters changed since factory
setting. Only the changed parameters in current edit-setup
are listed in changes made.
If the parameter's value is changed back to the factory
settings from another different value, the parameter will
NOT be listed in Changes Made.
1. Press [Menu] key to enter the Quick Menu until
indicator in display is placed above Quick Menu.
▲ ▼
2.
Press [ ] [ ] to select either FC 101 wizard,
closed-loop setup, motor setup or changes made,
then press [OK].
▲ ▼
3.
Press [ ] [ ] to browse through the parameters
in the Quick Menu.
4. Press [OK] to select a parameter.
▲ ▼
5.
Press [ ] [ ] to change the value of a parameter
setting.
6. Press [OK] to accept the change.
7. Press either [Back] twice to enter "Status", or
press [Menu] once to enter "Main Menu".

2.3.4 Main Menu

[Main Menu] is used for programming all parameters. The
Main Menu parameters can be accessed immediately
unless a password has been created via 0-60 Main Menu
Password. For the majority of VLT HVAC Basic Drive
applications, it is not necessary to access the Main Menu
parameters but instead the Quick Menu provides the
®
VLT HVAC Basic Drive Programming Guide
Default Function
Size related Ramp-up time
from 0 to rated
1-23 Motor
Frequency
Size related Ramp-down time
from rated
1-23 Motor
Frequency to 0
0.0 Hz Enter the
minimum limit
for low speed
65 Enter the
maximum limit
for high speed
Size related Enter the
maximum output
frequency value
®
MG18B222 - VLT is a registered Danfoss trademark
simplest and quickest access to the typical required
parameters.
The Main Menu accesses all parameters.
1. Press [Menu] key until indicator in display is
placed above "Main Menu".
▲ ▼
2.
Use [ ] [ ] to browse through the parameter
groups.
3. Press [OK] to select a parameter group.
▲ ▼
4.
Use [ ] [ ] to browse through the parameters in
the specific group.
5. Press [OK] to select the parameter.
▲ ▼
6.
Use [ ] [ ] to set/change the parameter value.
[Back] is used to go one level back.
