Danfoss VLT HVAC Basic Drive FC 100 Series Programming Manual page 53

Parameters
[64] Comparator 4 See parameter group 13-1*. If Comparator
4 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[65] Comparator 5 See parameter group 13-1*. If Comparator
5 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[70] Logic Rule 0 See parameter group 13-4*. If Logic Rule 0
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[71] Logic Rule 1 See parameter group 13-4*. If Logic Rule 1
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[72] Logic Rule 2 See parameter group 13-4*. If Logic Rule 2
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[73] Logic Rule 3 See parameter group 13-4*. If Logic Rule 3
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[74] Logic Rule 4 See parameter group 13-4*. If Logic Rule 4
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[75] Logic Rule 5 See parameter group 13-4*. If Logic Rule 5
is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[80] SL Digital See 13-52 SL Controller Action. The input
Output A will go high whenever the Smart Logic
Action [38] Set dig. out. A high is
executed. The input will go low whenever
the Smart Logic Action [32] Set dig. out. A
low is executed.
[81] SL Digital See 13-52 SL Controller Action. The input
Output B will go high whenever the Smart Logic
Action [39] Set dig. out. Bhigh is executed.
The input will go low whenever the Smart
Logic Action [33] Set dig. out. B low is
executed.
[82] SL Digital See 13-52 SL Controller Action. The input
Output C will go high whenever the Smart Logic
Action [40] Set dig. out. C high is executed.
The input will go low whenever the Smart
Logic Action [34] Set dig. out. C low is
executed.
[83] SL Digital See 13-52 SL Controller Action. The input
Output D will go high whenever the Smart Logic
Action [41] Set dig. out. D high is
executed. The input will go low whenever
the Smart Logic Action [35] Set dig. out. D
low is executed.
[84] SL Digital See 13-52 SL Controller Action. The input
Output E will go high whenever the Smart Logic
Action [42] Set dig. out. E high is executed.
The input will go low whenever the Smart
Logic Action [36] Set dig. out. E low is
executed.
®
VLT HVAC Basic Drive Programming Guide
[85]
[160] No alarm
[161] Running
[165] Local reference
[166] Remote
[167] Start
[168] Drive in hand
[169] Drive in auto
[180] Clock Fault
[181] Preventive
[193] Sleep Mode
[194] Broken Belt
[196] Fire Mode
[198] Drive Bypass
®
MG18B222 - VLT is a registered Danfoss trademark
SL Digital See 13-52 SL Controller Action. The input
Output F will go high whenever the Smart Logic
Action [43] Set dig. out. F high is executed.
The input will go low whenever the Smart
Logic Action [37] Set dig. out. F low is
executed.
The output is high when no alarm is
present.
The output is high when the adjustable
reverse frequency drive is running counter-
clockwise (the logical product of the
status bits 'running' AND 'reverse').
The output is high when 3-13 Reference
active Site = [2] Local or when 3-13 Reference Site
= [0] Linked to hand auto at the same time
as the LCP is in [Hand On] mode.
The output is high when 3-13 Reference
reference Site [1] or Linked to hand/auto [0] while
active the LCP is in [Auto on] mode.
The output is high when there is an
command active Start command (i.e. via digital input
active bus connection or [Hand on] or [Auto on],
and no Stop command is active).
The output is high when the adjustable
mode frequency drive is in Hand on mode (as
indicated by the LED light above [Hand
on]).
The output is high when the adjustable
mode frequency drive is in Hand on mode (as
indicated by the LED light above [Auto
on]).
The clock function has been reset to
default (2000-01-01) because of a power
failure.
One or more of the preventive
Maintenance maintenance events programmed in
23-10 Maintenance Item has passed the
time for the specified action in
23-11 Maintenance Action.
The adjustable frequency drive/system has
set to sleep mode. See parameter group
22-4*.
A Broken Belt condition has been
detected. This function must be enabled
in 22-60 Broken Belt Function.
The adjustable frequency drive is
operating in Fire Mode. See parameter
group 24-0* Fire Mode.
To be used as signal for activating an
external electromechanical bypass
switching the motor direct on line. See
24-1* Drive Bypass.
