Danfoss VLT HVAC Basic Drive FC 100 Series Programming Manual page 22

How to Program
Closed-loop Set-up Wizard
2 2
No & Name
0-03 Regional Settings
0-06 GridType
1-00 Configuration Mode
1-10 Motor Construction
1-20 Motor Power
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
1-26 Motor Cont. Rated Torque
1-29 Automatic Motor Adaption
(AMA)
1-30 Stator Resistance (Rs)
1-37 d-axis Inductance (Ld)
2-8
®
VLT HVAC Basic Drive Programming Guide
Range
[0] International
[1] US
[0] -[[132] please see start-up
wizard for open-loop
application
[0] Open-loop
[3] Closed-loop
*[0] Motor construction
[1] PM, non-salient SPM
0.125–150 hp [0.09–110 kW]
50.0–1,000.0 V
20.0–400.0 Hz
0.0–10,000.00 A
100.0–9,999.0 RPM
0.1–1,000.0
0.000–99.990
0–1000
®
MG18B222 - VLT is a registered Danfoss trademark
Default Function
0
Size selected Select operating mode for restart upon
reconnection of the adjustable frequency
drive to AC line voltage after power-down.
0 Change this parameter to Closed-loop
[0] Asynchron Setting the parameter value might change
these parameters:
1-01 Motor Control Principle
1-03 Torque Characteristics
1-14 Damping Gain
1-15 Low Speed Filter Time Const.
1-16 High Speed Filter Time Const.
1-17 Voltage filter time const.
1-20 Motor Power [kW]
1-22 Motor Voltage
1-23 Motor Frequency
1-25 Motor Nominal Speed
1-26 Motor Cont. Rated Torque
1-30 Stator Resistance (Rs)
1-33 Stator Leakage Reactance (X1)
1-35 Main Reactance (Xh)
1-37 d-axis Inductance (Ld)
1-39 Motor Poles
1-40 Back EMF at 1000 RPM
1-66 Min. Current at Low Speed
1-72 Start Function
1-73 Flying Start
4-19 Max Output Frequency
4-58 Missing Motor Phase Function
Size related Enter motor power from nameplate data
Size related Enter motor voltage from nameplate data
Size related Enter motor frequency from nameplate data
Size related Enter motor current from nameplate data
Size related Enter motor nominal speed from nameplate
data
Size related This parameter is available only when
1-10 Motor Construction Design is set to [1]
PM, non-salient SPM.
NOTE!
Changing this parameter will affect
settings of other parameters
Off Performing an AMA optimizes motor
performance.
Size related Set the stator resistance value
Size related Enter the value of the d-axis inductance.
Obtain the value from the permanent magnet
motor data sheet. The de-axis inductance
cannot be found by performing an AMA.
