5.1.5 3-** Reference/Ramps

Par. Parameter description
No. #
3-0* Reference Limits
3-02 Minimum Reference
3-03 Maximum Reference
3-1* References
3-10 Preset Reference
3-11 Jog Speed [Hz]
3-14 Preset Relative Reference
3-15 Reference 1 Source
3-16 Reference 2 Source
3-17 Reference 3 Source
3-4* Ramp 1
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
3-5* Ramp 2
3-51 Ramp 2 Ramp Up Time
3-52 Ramp 2 Ramp Down Time
3-8* Other Ramps
3-80 Jog Ramp Time
3-81 Quick Stop Ramp Time
Table 5.6
®
VLT HVAC Basic Drive Programming Guide
Default value
0 ReferenceFeedbackUnit
ExpressionLimit
0 %
5 Hz
0 %
[1] Analog in 53
[2] Analog in 54
[11] Local bus reference
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
®
MG18B222 - VLT is a registered Danfoss trademark
2-set-up Change Conver-
during sion index
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
Type
-3 Int32
-3 Int32
-2 Int16 5 5
-1 Uint16
-2 Int16
- Uint8
- Uint8
- Uint8
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint32
5-5
