Danfoss VLT HVAC Basic Drive FC 100 Series Programming Manual page 94

Troubleshooting
No. Description
50 AMA Calibration Failed
51 AMA check Unom and Inom
52 AMA low I
53 AMA motor too big
54 AMA motor too small
55 AMA Parameter out of range
4 4
56 AMA interrupted by user
57 AMA timeout
58 AMA internal fault
59 Current limit
60 External Interlock
66 Heatsink Temperature Low
69 Pwr Card Temperature
79 Illegal PS config
80 Drive Initialized to Default Value
87 Auto DC Braking
95 Broken Belt
201 Fire Mode
202 Fire M Limits Exceeded
250 New spare parts
251 New Type Code
Table 4.1 Alarm/Warning code list
(X) Dependent on parameter
A trip is the action when an alarm has appeared. The trip
will coast the motor and can be reset by pressing the reset
button or make a reset by a digital input (parameter group
5-1* [1]). The original event that caused an alarm cannot
damage the adjustable frequency drive or cause dangerous
conditions. A trip lock is an action that occurs in
conjunction with an alarm, which may cause damage to
the adjustable frequency drive or connected parts. A trip
lock situation can only be reset by power cycling.
LED indication
Warning
Alarm
Table 4.2
The alarm words, warning words and extended status
words can be read out via serial bus or optional serial
communication bus for diagnosis. See also 16-90 Alarm
Word, 16-92 Warning Word and 16-94 Ext. Status Word.
4-2
VLT
nom
yellow
flashing red
MG18B222 - VLT
®
HVAC Basic Drive Programming Guide
Warning Alarm
X
X
X
X
X
X
X
X
X X
X
X
X
X X
X X
X
X
X X
X
X
X
X
®
is a registered Danfoss trademark
Trip Lock Parameter Reference
X
22-6*
X
X
